TRANSMISSION (020 021 022)
Parts (22)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 25500-98L00 | GEAR SET REVERSE Price: Call Us |
| 2 | 25711-98L00 | SHIFTER CLUTCH DOG Price: Call Us |
| 3 | 09140-36003 | NUT (M36 T:6) Price: Call Us |
| 4 | 09159-16027 | NUT (M16) Price: Call Us |
| 5 | 09160-16026 | WASHER (16X30X3) Price: Call Us |
| 9 | 56120-98L00 | HOUSING PROP SHAFT BRG Price: Call Us |
| 15 | 56122-98L00 | STOPPER PROP SHAFT BRG HSG Price: Call Us |
| 18 | 56150-98L02 | HOUSING REV PINION BRG Price: Call Us |
| 23 | 09280-21015 | O RING (D:2.7 ID:21.4) Price: Call Us |
| 24 | 09280-26006 | O RING (D:3.1 ID:26.4) Price: Call Us |
| 25 | 09421-04008 | KEY Price: Call Us |
| 30 | 09380-24007 | CIRCLIP Price: Call Us |
| 31 | 09159-16027 | NUT (M16) Price: Call Us |
| 33 | 08221-16256 | SHIM Price: Call Us |
| 36 | 57301-98810 | GEAR SET CONTRA Price: Call Us |
| 39 | 57610-98L00 | SHAFT PROPELLER INNER Price: Call Us |
| 40 | 57622-98L00 | SPACER PROP SHAFT Price: Call Us |
| 41 | 09160-36007 | WASHER (32X47X2) Price: Call Us |
| 42 | 57600-98840 | SHAFT SET PROPELLER OUTER This part replaces 57600-98822. Price: Call Us |
| 47 | 57635-98L00 | STOPPER PROPELLER SHAFT Price: Call Us |
| 48 | 17450-98L04 | HOUSING WATER INLET Price: Call Us |
| 49 | 09280-69001 | O RING (D:3.1 ID:68.5) Price: Call Us |
