| Ref | Part Number | Description |
|---|
| 120 |
120CB0512 |
BOLT-SOCKET,5X12 This part replaces 120S0512. Price: $1.76 |
| 120A |
120CB0618 |
BOLT-SOCKET,6X18 This part replaces 120S0618. Price: $1.78 |
| 220 |
220AB0608 |
SCREW-PAN-CROSS This part replaces 220F0608. Price: $1.81 |
| 221 |
221AB0630 |
SCREW-CSK-CROS,6X30 This part replaces 221F0630. Price: $1.81 |
| 311 |
311AB0500 |
NUT-HEX,5MM This part replaces 311C0500. Price: $0.43 |
| 461 |
461DB0500 |
WASHER-SPRING,5MM This part replaces 461K0500. Price: $1.50 |
| 461A |
461DA0600 |
WASHER-SPRING,6MM This part replaces 461L0600. Price: $0.71 |
| 11047 |
11047-1280 |
BRACKET,REFLECTOR Price: $38.50 |
| 11051 |
11051-1268 |
BRACKET,SEAT LOCK Price: $11.75 |
| 11051A |
11051-1276 |
BRACKET,SIDE REFLECTO Price: $22.32 |
| 21007 |
21007-5037 |
ROTOR,LOCK,TANK CAP This part replaces 21007-5042. Price: $92.36 |
| 27005 |
27005-5122 |
SWITCH-ASSY-IGNITION Price: $170.83 |
| 27010B |
27010-1452 |
SWITCH,BRAKE LAMP Price: $32.39 |
| 27010C |
27010-1469 |
SWITCH,SIDE STAND Price: $73.36 |
| 27011 |
27011-021 |
BRAKE SWITCH SPRING Price: $24.57 |
| 27016 |
27016-1098 |
LOCK-ASSY,SEAT STRIKER Price: $84.75 |
| 27016A |
27016-1113 |
LOCK-ASSY,SEAT STRIKE Price: $73.40 |
| 27016B |
27016-5212 |
LOCK-ASSY,HELMET This part replaces 27016-5249. Price: $81.78 |
| 27016C |
27016-5257 |
LOCK-ASSY,SEAT Price: $73.40 |
| 27045 |
27045-5147 |
SWITCH-ASSY Price: $391.15 |
| 28012 |
28012-1003 |
REFLECTOR-REFLEX Price: $22.09 |
| 28012A |
28012-1077 |
REFLECTOR-REFLEX Price: $23.25 |
| 28012B |
28012-1088 |
REFLECTOR-REFLEX Price: $22.46 |
| 54010 |
54010-1115 |
CABLE,SEAT LOCK,FR Price: $18.85 |
| 54010A |
54010-1116 |
CABLE,SEAT LOCK,TANDE Price: $18.85 |
| 92002 |
112BA0612 |
BOLT-UPSET This part replaces 92002-1132. Price: $1.49 |
| 92002A |
92002-1582 |
BOLT,FLANGED,6X25 Price: $4.69 |
| 92015 |
92015-1367 |
NUT,FLANGED,6MM Price: $3.69 |
| 92151 |
92153-0967 |
BOLT,TORX,6X16 This part replaces 92151-1911. Price: $2.61 |
