Cowling Lowers 2
Parts (33)
| Ref | Part Number | Description |
|---|---|---|
| 10 | 513033667 | Fuel Tank Price: $349.99 |
| 20 | 513033860 | Fuel Tank Cap Price: $25.99 |
| 60 | 513033842 | Check Valve Price: $36.99 |
| 70 | 513033596 | Grommet Price: $21.99 |
| 80 | 219704410 | Polyurethane Hose 10000Mm Long Price: $57.99 |
| 90 | 293750008 | Tie Wrap 368 mm Price: $1.04 |
| 95 | 414227300 | Clip Price: $1.69 |
| 300a | 415129451 | Fuel Filter Price: $25.99 |
| 300b | 414872100 | Fuel Filter Strainer Price: $12.49 |
| 300c | 415129821 | Regulator Price: $82.99 |
| 300d | 415129822 | O-Ring Price: $19.99 |
| 300e | 415129823 | O-Ring Price: $19.99 |
| 300f | 415130108 | Fuel Level Sensor Price: $154.99 |
| 310 | 513033180 | Ring Price: $19.99 |
| 320 | 513033334 | Gasket Price: $25.99 |
| 400 | 513033418 | RH Cap Price: $15.49 |
| 410 | 513033419 | LH Cap Price: $15.49 |
| 420 | 513033326 | Shoulder Bushing Price: $15.49 |
| 500a | 293650125 | Oetiker Clamp Price: $3.39 |
| 500b | 513034047 | Fuel Filter This part replaces 513033719. Price: $21.99 |
| 510 | 293650053 | Crimp Clamp Price: $3.19 |
| 560a | 513033135 | Locking Clip Price: $5.99 |
| 570 | 513033542 | Bracket Price: $15.49 |
| 575 | 513033593 | Bracket Price: $18.99 |
| 580 | 207551044 | Hex. Flange Screw M5 X 10 Price: $4.19 |
| 600 | 513033648 | Fuel Hose Ass'y Price: $134.99 |
| 650 | 414115200 | Tie-Rap 180 mm Price: $0.11 |
| 800 | 513033588 | Insulating Foam Price: $15.49 |
| 92172 | 92172-0262 | SCREW,TAPPING,5X10 Price: $1.34 |
| 92172A | 92172-0821 | SCREW,5X12 Price: $0.85 |
| 92200 | 92200-0006 | WASHER,NYLONE,5.3X11.5X0.5 Price: $1.86 |
| 92200A | 92200-0157 | WASHER,10.4X15.9X0.5 Price: $2.15 |
| 92200B | 92200-0857 | WASHER,5.5X18X1.6 Price: $1.19 |
