| Ref | Part Number | Description |
|---|
| 130 |
130BA0508 |
BOLT-FLANGED,5X8 This part replaces 130G0508. Price: $1.86 |
| 223 |
223AA0410 |
SCREW-PAN-WS-CROS This part replaces 223D0410. Price: $0.68 |
| 11065 |
11065-0018 |
CAP Price: $6.12 |
| 13271 |
13271-0056 |
PLATE Price: $3.74 |
| 14091 |
14091-0055 |
COVER,THROTTLE-BODY Price: $11.88 |
| 16014 |
16014-0002 |
SCREW-PILOT AIR Price: $25.16 |
| 16021 |
16021-0002 |
SCREW-THROTTLE STOP Price: $79.62 |
| 16073 |
16073-3707 |
INSULATOR Price: $6.18 |
| 16163 |
16163-0032 |
THROTTLE-ASSY Price: $1,987.34 |
| 16170 |
16170-0004 |
LINK-ASSY Price: $239.55 |
| 21176 |
21176-0002 |
SENSOR,TPS,MAIN Price: $217.59 |
| 21176A |
21176-0003 |
SENSOR,MAIN Price: $217.59 |
| 26031 |
26031-0405 |
HARNESS This part replaces 26031-0040. Price: $475.67 |
| 31064 |
31064-0005 |
PIPE-COMP Price: $24.61 |
| 49033 |
49033-1060 |
NOZZLE-INJECTION Price: $140.46 |
| 49056 |
49056-0001 |
PIPE-INJECTION Price: $103.85 |
| 59071 |
59071-0014 |
JOINT,4WAY Price: $14.58 |
| 59071A |
59071-3752 |
JOINT,3WAY,T Price: $10.19 |
| 92001 |
92001-1998 |
BOLT,THROTTLE ADJUST Price: $16.94 |
| 92055 |
92055-1622 |
RING-O,INJECTION NOZZLE Price: $1.95 |
| 92055A |
92055-1671 |
RING-O Price: $3.73 |
| 92072 |
92072-0012 |
BAND,SUB-HARNESS Price: $5.00 |
| 92081 |
92081-1620 |
SPRING Price: $4.96 |
| 92144 |
92144-1451 |
SPRING Price: $9.58 |
| 92153 |
92153-1244 |
BOLT,SOCKET,5X16 Price: $2.41 |
| 92172 |
92172-0064 |
SCREW,PIPE INJECTION Price: $2.80 |
| 92172A |
92172-0065 |
SCREW,THROTTLE SYNCRO Price: $3.04 |
| 92172B |
92172-0080 |
SCREW Price: $5.00 |
| 92191 |
92191-0025 |
TUBE Price: $2.43 |
| 92191A |
92191-0036 |
TUBE Price: $4.41 |
| 92191B |
92191-0038 |
TUBE Price: $13.58 |
| 92192 |
92192-0018 |
TUBE,3X7X95 Price: $4.22 |
| 92192A |
92192-0019 |
TUBE,3X7X170 Price: $12.96 |
