| Ref | Part Number | Description |
|---|
| 2 |
320B1400 |
NUT-CASTLE,14MM Price: $6.71 |
| 5 |
41055-003 |
PIN BRAKE CONNECT ROD Price: $9.02 |
| 6 |
41053-011 |
LEVER FRT BRK CAM 1ST Price: $30.73 |
| 7 |
550AA1210 |
PIN-COTTER,1.2X10 This part replaces 550D1210. Price: $2.65 |
| 8 |
41056-001 |
SPRING FR BRK CAM LEV Price: $10.17 |
| 9 |
41051-001 |
SEAL,BRAKE CAM Price: $4.26 |
| 10 |
41052-005 |
WASHER,BRAKE CAMSHAFT Price: $3.71 |
| 11 |
41058-008 |
ROD END,BRK CONNECT Price: $13.82 |
| 12 |
311AA0500 |
NUT-HEX,5MM This part replaces 311B0500. Price: $0.47 |
| 13 |
41057-004 |
ROD BRK CAM LEV CONCT Price: $39.96 |
| 14 |
112BA0630 |
BOLT-UPSET This part replaces 112G0630. Price: $1.38 |
| 15 |
41058-009 |
ROD END,BRK CONNECT Price: $14.49 |
| 16 |
41053-012 |
LEVER FRT BRK CAM 2ND Price: $21.88 |
| 18 |
112BA0618 |
BOLT-UPSET This part replaces 112G0618. Price: $1.03 |
| 19 |
411AA0600 |
WASHER-PLAIN,6MM This part replaces 411B0600. Price: $2.92 |
| 20 |
41063-003 |
WASHER PINION THRUST Price: $4.64 |
| 21 |
41060-007 |
PINION SPEEDOMETER Price: $16.38 |
| 22 |
41062-003 |
BUSH SPEDMETER PINION Price: $29.59 |
| 24 |
41048-1090 |
SHOE-BRAKE This part replaces 41048-019. Price: $32.24 |
| 25 |
41049-004 |
SPRING FRNT BRK SHOE Price: $4.84 |
| 26 |
41034-007 |
DRUM-ASSY,FR BRK Price: $184.46 |
| 27 |
41059-009 |
GEAR SPEEDOMETER Price: $22.70 |
| 28 |
92050-017 |
OIL SEAL WOC55687 Price: $35.72 |
| 29 |
601B6302Z |
BEARING BALL #6302Z Price: $27.38 |
| 30 |
41039-011 |
SPACER F AXLE BEARING Price: $8.54 |
| 31 |
601B6302 |
BEARING BALL #6302 Price: $9.05 |
| 32 |
92052-005 |
OIL SEAL WTC25428 Price: $24.82 |
| 33 |
41069-007 |
COLLAR F AXL OIL SEAL Price: $5.54 |
