| Ref | Part Number | Description |
|---|
| 1 |
11009-1278 |
GASKET-MIXING CHAMBER Price: $7.22 |
| 2 |
11009-1279 |
GASKET-FAST IDLE Price: $11.82 |
| 3 |
16019-024 |
O RING,FLOAT BALL Price: $25.28 |
| 4 |
13070-1060 |
GUIDE-THROTTLE Price: $17.56 |
| 5 |
13169-1492 |
PLATE-CHOKE CAM Price: $6.23 |
| 6 |
14025-1452 |
COVER-FAST IDLE Price: $16.67 |
| 7 |
16001-1912 |
CARBURETOR Price: $337.23 |
| 8 |
16002-1002 |
ADJUSTER,CABLE Price: $11.71 |
| 9 |
16005-1014 |
CHAMBER-MIXING,TOP Price: $40.17 |
| 10 |
16007-1049 |
SEAT-SPRING,THROTTLE Price: $10.37 |
| 11 |
16009-1104 |
NEEDLE-JET Price: $37.01 |
| 12 |
16014-1029 |
SCREW,PILOT ADJUST Price: $19.09 |
| 13 |
16017-1001 |
NEEDLE JET Price: $43.70 |
| 14 |
16021-1037 |
SCREW-THROTTLE STOP Price: $17.15 |
| 15 |
16025-1064 |
VALVE-THROTTLE,#2 Price: $119.53 |
| 16 |
16030-1007 |
VALVE-FLOAT Price: $47.99 |
| 17 |
16031-1001 |
FLOAT Price: $64.24 |
| 18 |
16041-1026 |
SHAFT-CARB,FAST IDLE Price: $16.37 |
| 19 |
16065-1053 |
HOLDER-NEEDLE JET Price: $29.31 |
| 20 |
16065-1064 |
HOLDER-CARBURETOR Price: $31.20 |
| 21 |
21083-1013 |
ARM-IDLE PLATE Price: $12.45 |
| 22 |
49006-1007 |
CAP,CABLE ADJUSTER Price: $15.51 |
| 23 |
49040-1006 |
PUMP-FUEL Price: $346.76 |
| 24 |
92009-1434 |
SCREW,DRAIN,M6X1.0 This part replaces 92009-1095. Price: $8.38 |
| 25 |
92022-1003 |
WASHER,PLAIN Price: $4.31 |
| 26 |
92022-1308 |
WASHER-CHOKE CAM Price: $4.64 |
| 27 |
92027-1581 |
COLLAR,6X22 Price: $3.25 |
| 28 |
16044-007 |
CLAMP,FLOAT VALVE Price: $7.91 |
| 29 |
92037-1039 |
CIRCLIP,JET NEEDLE Price: $4.58 |
| 30 |
92037-1142 |
CLAMP,TUBE Price: $4.31 |
| 31 |
92037-1395 |
CLAMP,FUEL HOSE Price: $3.42 |
| 32 |
92037-178 |
CLAMP,CARBURETOR HLDR Price: $8.31 |
| 33 |
92043-1002 |
FLOAT PIN Price: $6.25 |
| 34 |
92055-1002 |
RING-O,PILOT ADJUST Price: $4.31 |
| 35 |
92055-1053 |
RING-O Price: $4.69 |
| 36 |
92059-1046 |
HOSE,FUEL OVERFLOW Price: $17.42 |
| 37 |
92059-1283 |
TUBE,4.5X8.5X700 Price: $5.03 |
| 38 |
92063-1009 |
MAIN JET,#105 Price: $15.76 |
| 38 |
92063-1114 |
JET-MAIN #110 Price: $14.79 |
| 38 |
92063-1116 |
JET-MAIN,#108 Price: $14.79 |
| 38 |
92063-1117 |
JET-MAIN,#112 Price: $14.79 |
| 38 |
92063-1118 |
JET-MAIN,#115 Price: $14.79 |
| 39 |
92064-1048 |
JET-PILOT #42 Price: $17.95 |
| 40 |
92075-1481 |
DAMPER,FUEL PUMP Price: $7.13 |
| 41 |
92081-1002 |
SPRING,PILOT ADJUST SCREW Price: $5.46 |
| 42 |
92081-1619 |
SPRING,SHAFT STOP This part replaces 92081-1249. Price: $7.55 |
| 43 |
92081-1435 |
SPRING-THROTTLE VALVE Price: $8.73 |
| 44 |
92081-1436 |
SPRING-FAST IDLE Price: $4.06 |
| 45 |
92081-1437 |
SPRING-THROTTLE STOP Price: $3.59 |
| 46 |
92140-1007 |
BALL-CHOKE CAM Price: $6.44 |
| 47 |
220AA0408 |
SCREW-PAN-CROS,4X8 This part replaces 220B0408. Price: $0.68 |
| 48 |
220AA0414 |
SCREW-PAN-CROS This part replaces 220B0414. Price: $4.60 |
| 49 |
220AA0614 |
SCREW-PAN-CROS,6X14 This part replaces 220B0614. Price: $1.48 |
| 50 |
311AA0500 |
NUT-HEX,5MM This part replaces 311B0500. Price: $0.47 |
| 51 |
461F0400 |
WASHER SPRING 4MM Price: $0.47 |
| 52 |
461DA0500 |
WASHER-SPRING,5MM This part replaces 461F0500. Price: $0.71 |
| 53 |
110R0635 |
BOLT 6X35 Price: $5.96 |
| 54 |
461DA0800 |
WASHER-SPRING,8MM This part replaces 461F0800. Price: $0.40 |
| 55 |
92022-1565 |
WASHER,6.5X16X2 Price: $3.92 |
