| Ref | Part Number | Description |
|---|
| 1 |
112BA0625 |
BOLT-UPSET,6X25 This part replaces 112G0625. Price: $3.72 |
| 2 |
16001-1250 |
CARBURETOR ASSY Price: $279.84 |
| 3 |
16065-1007 |
HOLDER,CARBURETOR Price: $120.10 |
| 4 |
92036-018 |
RING-SNAP Price: $3.89 |
| 5 |
92037-061 |
CLAMP-INLET PIPE Price: $17.74 |
| 6 |
92011-037 |
SCREW,PAN HEAD Price: $5.71 |
| 7 |
11009-1079 |
GASKET,FLOAT CHAMBER Price: $16.29 |
| 8 |
92064-024 |
JET-PILOT NO 40 Price: $22.86 |
| 9 |
16038-009 |
GASKET-COVER Price: $9.73 |
| 10 |
16049-006 |
COVER,MAIN JET Price: $20.47 |
| 11 |
11009-1080 |
PLATE,FLOAT CHAMBER Price: $16.29 |
| 12 |
16076-003 |
CIRCLIP Price: $8.92 |
| 13 |
16030-022 |
FLOAT VALVE ASSY Price: $33.19 |
| 14 |
16032-008 |
PIN,FLOAT Price: $6.57 |
| 15 |
11009-1076 |
GASKET,FLOAT VALVE Price: $4.94 |
| 16 |
16009-1063 |
JET NEEDLE,6DH7 Price: $23.67 |
| 17 |
16017-1060 |
NEEDLE JET,Q-4 Price: $34.25 |
| 18 |
16065-1017 |
HOLDER,NEEDLE JET Price: $37.32 |
| 19 |
92063-1087 |
MAIN JET,#A137.5 Price: $22.19 |
| 20 |
16031-025 |
FLOAT ASSY Price: $82.44 |
| 22 |
220AA0516 |
SCREW-PAN-CROS,5X16 This part replaces 220B0516A. Price: $2.06 |
| 23 |
461DA0500 |
WASHER-SPRING,5MM This part replaces 461F0500. Price: $0.71 |
| 24 |
92059-1017 |
TUBE,3.5X6.5X290,BRTH Price: $6.72 |
| 25 |
92059-1084 |
HOSE,6.5X11.5X240 Price: $21.68 |
| 26 |
92037-056 |
CLAMP,CARB CONECT HOS Price: $6.60 |
| 27 |
16022-007 |
SPRING,PILOT AIR SCREW Price: $8.13 |
| 28 |
16014-006 |
SCREW Price: $17.15 |
| 29 |
16002-1006 |
ADJUSTER,CABLE Price: $10.89 |
| 30 |
16003-004 |
NUT CABLE ADJUST LOCK Price: $7.34 |
| 31 |
13070-1010 |
GUIDE,CABLE Price: $27.59 |
| 32 |
16008-011 |
CIRCLIP,CABLE GUIDE Price: $6.85 |
| 33 |
11009-1191 |
GASKET,CABLE GUIDE Price: $9.73 |
| 34 |
16004-1003 |
TOP,MIXING CHAMBER Price: $33.88 |
| 35 |
16006-016 |
SPRING-THROTTLE VALVE Price: $24.74 |
| 36 |
16021-1028 |
SCREW,THROTTLE ADJUST Price: $11.48 |
| 37 |
92081-1200 |
SPRING,THRTL STP SCRW Price: $9.28 |
| 38 |
92009-1037 |
SCREW,4X5 Price: $3.56 |
| 39 |
16008-010 |
CIRCLIP Price: $9.21 |
| 40 |
16007-1007 |
SEAT,THROTTLE VALVE Price: $12.19 |
| 41 |
16025-1047 |
VALVE,THROTTLE,CA2.0 Price: $77.81 |
| 42 |
16013-008 |
SPRING,STARTER PLUNGER Price: $6.46 |
| 43 |
16012-016 |
CAP,PLUNGER Price: $9.66 |
| 44 |
16073-014 |
COLLAR Price: $10.47 |
| 45 |
16016-1014 |
PLUNGER ASSY,STARTER Price: $29.04 |
| 46 |
16039-015 |
CAP,RUBBER,STARTER PLUNGE Price: $6.88 |
| 47 |
16013-009 |
SPRING,STATER LEVER Price: $6.00 |
