| Ref | Part Number | Description |
|---|
| 1 |
16082-066 |
OIL PUMP ASSY Price: $336.20 |
| 2 |
16085-026 |
GEAR,OIL PUMP Price: $37.01 |
| 3 |
16141-006 |
BODY,OIL PUMP Price: $24.49 |
| 4 |
16142-006 |
COVER,OIL PUMP Price: $29.63 |
| 5 |
16154-5001 |
ROTOR,OIL PUMP Price: $22.04 |
| 6 |
220AA0614 |
SCREW-PAN-CROS,6X14 This part replaces 220B0614. Price: $1.48 |
| 7 |
551A0608 |
PIN-DOWEL,6X8 Price: $3.92 |
| 8 |
92042-041 |
PIN,DOWEL,4X12.8 Price: $6.57 |
| 9 |
16084-018 |
GEAR,OIL PUMP Price: $11.54 |
| 10 |
11060-1115 |
GASKET,OIL PUMP Price: $5.18 |
| 11 |
16097-1001 |
FILTER-ASSY-OIL Price: $12.23 |
| 12 |
92071-100 |
GROMMET,OIL STRAINER Price: $5.46 |
| 13 |
16099-004 |
ELEMENT-OIL FILTER Price: $9.26 |
| 14 |
92071-101 |
GROMMET,OIL FILTER Price: $5.46 |
| 15 |
16156-002 |
PISTON-ASSY,VALVE,BY-PASS Price: $23.25 |
| 16 |
92043-123 |
PIN,SPRING,2.2X13.5 Price: $4.69 |
| 17 |
92081-043 |
SPRING,PISTON Price: $5.46 |
| 18 |
92136-002 |
VALVE Price: $4.65 |
| 19 |
220AA0625 |
SCREW-PAN-CROS,6X25 This part replaces 220B0625. Price: $2.78 |
| 20 |
315AA1600 |
NUT,16MM This part replaces 315B1600. Price: $4.34 |
| 21 |
420B1611 |
WASHER,LOCK,16M/M Price: $4.39 |
| 22 |
551A0312 |
PIN DOWEL 3X12 Price: $0.75 |
| 23 |
551A0608 |
PIN-DOWEL,6X8 Price: $3.92 |
