OIL PUMP
Parts (17)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 6HY-12170-01-00 | CAMSHAFT ASSY 1 Price: $317.95 |
| 2 | 6AH-11537-01-00 | GEAR, DRIVEN Price: $105.60 |
| 3 | 90105-081A7-00 | BOLT, FLANGE Price: $9.49 |
| 4 | 90201-08784-00 | WASHER, PLATE Price: $3.50 |
| 5 | 90282-05012-00 | KEY, STRAIGHT Price: $17.10 |
| 6 | 6AH-11536-00-00 | GEAR, DRIVE Price: $40.20 |
| 7 | 6AH-11557-00-00 | WASHER 1 Price: $8.10 |
| 8 | 90170-30009-00 | NUT Price: $20.20 |
| 9 | 90280-03017-00 | KEY, WOODRUFF This part replaces 90280-03M01-00. Price: $8.49 |
| 10 | 6FM-46241-00-00 | BELT Price: $32.75 |
| 11 | 6FM-46297-01-00 | COVER, DUST Price: $22.75 |
| 12 | 90480-10627-00 | GROMMET Price: $4.72 |
| 13 | 6FM-42617-00-00 | DAMPER, FORM Price: $22.55 |
| 14 | 6FM-81639-01-00 | COVER Price: $7.60 |
| 15 | 6AH-13300-00-00 | OIL PUMP ASSY Price: $176.90 |
| 17 | 90105-06035-00 | BOLT, FLANGE Price: $2.49 |
| 18 | 93102-22010-00 | OIL SEAL Price: $5.95 |
