| Ref | Part Number | Description |
|---|
| 1 |
34028-011 |
BAR-FOOTREST,L.H Price: $29.20 |
| 2 |
92022-204 |
WASHER PL 22.5X36X2.3 Price: $0.90 |
| 3 |
92043-080 |
PIN,8X31 Price: $5.52 |
| 4 |
550AA2515 |
PIN-COTTER,2.5X15 This part replaces 550D2515. Price: $0.47 |
| 5 |
34003-040 |
HOLDER-FOTREST BAR LH Price: $66.49 |
| 6 |
92003-076 |
BOLT-L.H FOOTREST FIT Price: $48.42 |
| 7 |
315AA1200 |
NUT-HEX-FINE This part replaces 315B1200. Price: $0.95 |
| 8 |
34003-041 |
HOLDER-FOTREST BAR RH Price: $50.76 |
| 9 |
461DA1200 |
WASHER-SPRING,12MM This part replaces 461F1200. Price: $1.03 |
| 10 |
92001-1068 |
BOLT,R.H.FOOTREST FIT Price: $7.38 |
| 11 |
34028-012 |
BAR-FOOTREST,R.H Price: $29.20 |
| 12 |
34028-009 |
STEP,RR Price: $26.11 |
| 13 |
92076-024 |
RUBBER,REAR FOOTREST Price: $24.87 |
| 14 |
92022-199 |
WASHER-PLAIN (OPT) Price: $11.60 |
| 15 |
92043-1464 |
PIN,6X28 Price: $8.10 |
| 16 |
550AA2012 |
PIN,COTTER,2.0X12 This part replaces 550D2012. Price: $1.11 |
| 17 |
34029-011 |
BRACKET,REAR FOOTREST Price: $39.27 |
| 18 |
92092-010 |
BUSHING,MUFFLER FITT Price: $16.18 |
| 19 |
92022-196 |
WASHER-HANDLEBAR FIT Price: $4.63 |
| 20 |
411AA1000 |
WASHER-PLAIN,10MM This part replaces 411B1000. Price: $0.96 |
| 21 |
92210-1184 |
NUT,LOCK,10MM This part replaces 92019-021. Price: $6.11 |
| 22 |
34019-011 |
SHAFT MAIN STAND Price: $16.36 |
| 23 |
34023-010 |
SPRING-MAIN STAND Price: $15.71 |
| 24 |
34011-035 |
STAND-MAIN Price: $85.00 |
| 25 |
550AA3025 |
PIN-COTTER,3.0X25 This part replaces 550D3025. Price: $0.62 |
| 26 |
92075-115 |
DAMPER RUBB-MAIN STND Price: $9.48 |
| 28 |
34023-005 |
SPRING MAIN STAND Price: $10.92 |
| 30 |
461DA1000 |
WASHER-SPRING,10MM This part replaces 461F1000. Price: $0.68 |
| 31 |
314AA1000 |
NUT-HEX-FINE This part replaces 314B1000. Price: $0.68 |
| 32 |
92160-1655 |
DAMPER,SIDE STAND This part replaces 92075-031. Price: $10.21 |
| 33 |
43005-033 |
SPRING,BRAKE PEDAL Price: $7.78 |
| 34 |
43001-060 |
PEDAL,BRAKE Price: $51.23 |
| 35 |
482K0200 |
CIRCLIP 12MM Price: $1.63 |
| 36 |
550AA2015 |
PIN-COTTER,2.0X15 This part replaces 550D2015. Price: $1.12 |
| 37 |
410AA0600 |
WASHER-PLAIN-SMALL This part replaces 410B0600. Price: $1.31 |
| 38 |
92043-034 |
PIN R BRK CABLE JOINT Price: $9.19 |
| 39 |
112BA0622 |
BOLT-UPSET This part replaces 112B0622. Price: $3.74 |
| 40 |
311AA0600 |
NUT-HEX,6MM This part replaces 311B0600. Price: $0.96 |
