| Ref | Part Number | Description |
|---|
| 130 |
130BB0816 |
BOLT-FLANGED,8X16 This part replaces 130J0816. Price: $1.71 |
| 35019C |
35019-7503-6Z |
FLAP,RR,FR,RH,F.BLACK Price: $59.67 |
| 35019D |
35019-7504-6Z |
FLAP,RR,FR,LH,F.BLACK Price: $59.67 |
| 35019E |
35019-7505-6Z |
FLAP,RR,RR,F.BLACK Price: $25.62 |
| 35023 |
35023-0182-370 |
FENDER-REAR,CAMOUFLAG This part replaces 35023-0001-370. Price: $240.82 |
| 35063 |
35063-7505 |
STAY,REAR FENDER Price: $49.47 |
| 35063A |
35063-7508 |
STAY,REAR FENDER,LH Price: $21.08 |
| 35063B |
35063-7509 |
STAY,REAR FENDER,RH Price: $21.08 |
| 53004 |
53004-1173 |
MAT,REAR FENDER Price: $11.59 |
| 92009 |
92009-1166 |
SCREW,TAPPING,6X16 Price: $5.52 |
| 92009A |
92009-1465 |
SCREW,6X25 Price: $3.92 |
| 92009B |
92009-1694 |
SCREW,6X16 This part replaces 92009-1621. Price: $3.92 |
| 92015 |
92015-1233 |
NUT,FLANGED,6MM,BLACK Price: $5.52 |
| 92015A |
92015-1367 |
NUT,FLANGED,6MM Price: $3.69 |
| 92022 |
92022-1093 |
WASHER,6.5X16X1.0 Price: $2.08 |
| 92027 |
92027-1651 |
COLLAR,FLANGED,L=12.1,BLACK Price: $5.57 |
| 92027A |
92027-1964 |
COLLAR,L=4.7 Price: $7.34 |
| 92039 |
92039-0776 |
RIVET This part replaces 92039-1229. Price: $1.19 |
| 92071 |
92071-1237 |
GROMMET Price: $7.90 |
| 92072 |
92072-1361 |
BAND Price: $11.63 |
| 92075 |
92075-222 |
DAMPER,CASE Price: $7.34 |
