| Ref | Part Number | Description |
|---|
| 1 |
35004-1010 |
FENDER-FR Price: $101.64 |
| 2 |
35011-005 |
STAY FRONT FENDER Price: $37.35 |
| 3 |
220E0610 |
SCREW PAN HEAD 6X10 Price: $4.97 |
| 4 |
411AA0600 |
WASHER-PLAIN,6MM This part replaces 411B0600. Price: $2.92 |
| 5 |
461DA0600 |
WASHER-SPRING,6MM This part replaces 461F0600. Price: $0.71 |
| 6 |
312AA0600 |
NUT-HEX This part replaces 312B0600. Price: $0.73 |
| 7 |
115G0812 |
BOLT-SMALL-UPSET,8X12 This part replaces 114G0812. Price: $4.16 |
| 8 |
461DA0800 |
WASHER-SPRING,8MM This part replaces 461F0800. Price: $0.40 |
| 9 |
410AA0800 |
WASHER-PLAIN-SMALL,8MM This part replaces 410B0800. Price: $0.96 |
| 10 |
35023-1004 |
FENDER-RR Price: $108.24 |
| 11 |
35025-002 |
BRACKET REAR FENDER Price: $8.42 |
| 12 |
35013-012 |
PLATE,REAR FENDER Price: $6.00 |
| 13 |
110N0842 |
BOLT,HEX HEAD,8X42 Price: $2.50 |
| 14 |
411AA0800 |
WASHER-PLAIN,8MM This part replaces 411B0800. Price: $0.96 |
| 15 |
461DA0800 |
WASHER-SPRING,8MM This part replaces 461F0800. Price: $0.40 |
| 16 |
317AA0800 |
NUT-HEX-SMALL,8MM This part replaces 311B0800. Price: $0.68 |
| 17 |
220AA0612 |
SCREW-PAN-CROS,6X12 This part replaces 220B0612. Price: $1.19 |
| 18 |
411AA0600 |
WASHER-PLAIN,6MM This part replaces 411B0600. Price: $2.92 |
| 19 |
461DA0600 |
WASHER-SPRING,6MM This part replaces 461F0600. Price: $0.71 |
| 20 |
311AA0600 |
NUT-HEX,6MM This part replaces 311B0600. Price: $0.96 |
