| Ref | Part Number | Description |
|---|
| 132 |
132BA0616 |
BOLT-FLANGED-SMALL,6X16 This part replaces 132G0616. Price: $1.51 |
| 290 |
290Q0808 |
SCREW,8X8 Price: $4.78 |
| 480 |
480J1500 |
CIRCLIP-TYPE-C,15MM Price: $2.31 |
| 480A |
480J1600 |
CIRCLIP-TYPE-C,16MM Price: $4.31 |
| 13061 |
13061-1282 |
BOSS,KICK PEDAL Price: $77.63 |
| 13064 |
13064-1142 |
LEVER-ASSY-KICK,PEDAL Price: $159.95 |
| 13066 |
13066-1101 |
SHAFT-KICK This part replaces 13066-1019. Price: $102.46 |
| 13070 |
13070-1007 |
GUIDE,KICK SPRING Price: $10.97 |
| 13078 |
13078-1052 |
RATCHET,KL250-D2 Price: $66.54 |
| 13206 |
13206-1061 |
GUIDE-KICK This part replaces 13206-1001. Price: $11.80 |
| 59051 |
59051-1125 |
GEAR-SPUR,KICKSTARTER Price: $85.74 |
| 59051A |
59051-1191 |
GEAR-SPUR,IDLE,31T Price: $76.37 |
| 92001 |
92001-1034 |
BOLT,FLANGED,6X10 Price: $10.28 |
| 92022 |
92022-1205 |
WASHER,16.3X24X1 Price: $4.78 |
| 92022A |
92022-315 |
WASHER,16.8X22X0.5 Price: $6.22 |
| 92055 |
92055-061 |
O RING Price: $4.78 |
| 92081 |
92081-020 |
SPRING,KICK PEDAL Price: $4.26 |
| 92081A |
92081-122 |
SPRING,RATCHET Price: $8.79 |
| 92081B |
92081-1768 |
SPRING,KICKSTARTER Price: $17.39 |
