| Ref | Part Number | Description |
|---|
| 1 |
11034-1263 |
BRACKET,BRAKE PEDAL Price: $162.03 |
| 2 |
323N0800 |
NUT,CAP,8M/M Price: $4.60 |
| 3 |
112BA0622 |
BOLT-UPSET This part replaces 112B0622. Price: $3.74 |
| 4 |
115BA0825 |
BOLT-SMALL-UPSET,8X25 This part replaces 115G0825. Price: $5.42 |
| 5 |
311AA0600 |
NUT-HEX,6MM This part replaces 311B0600. Price: $0.96 |
| 6 |
43001-1024 |
PEDAL,BRAKE Price: $133.26 |
| 7 |
43004-1006 |
SHAFT,BRAKE Price: $55.28 |
| 8 |
461DA0800 |
WASHER-SPRING,8MM This part replaces 461F0800. Price: $0.40 |
| 9 |
92081-1088 |
SPRING,BRAKE PEDAL RT Price: $8.60 |
| 10 |
410AA0600 |
WASHER-PLAIN-SMALL This part replaces 410B0600. Price: $1.31 |
| 11 |
410AA1000 |
WASHER-PLAIN-SMALL,10MM This part replaces 410B1000. Price: $0.59 |
| 12 |
411AA0800 |
WASHER-PLAIN,8MM This part replaces 411B0800. Price: $0.96 |
| 13 |
461DA0800 |
WASHER-SPRING,8MM This part replaces 461F0800. Price: $0.40 |
| 14 |
461DA1000 |
WASHER-SPRING,10MM This part replaces 461F1000. Price: $0.68 |
| 15 |
550AA2020 |
PIN-COTTER,2.0X20 This part replaces 550D2020. Price: $1.04 |
| 16 |
92007-029 |
BOLT-HEX HEAD,10X46 Price: $10.00 |
| 17 |
92007-045 |
BOLT,HEX HEAD,10X25 Price: $10.62 |
