| Ref | Part Number | Description |
|---|
| 1 |
92001-1405 |
BOLT 8X38 Price: $16.50 |
| 2 |
461DA0800 |
WASHER-SPRING,8MM This part replaces 461F0800. Price: $0.40 |
| 3 |
46012-014 |
HOLDER,HANDLEBAR Price: $24.98 |
| 4 |
44001-192 |
FORK-FRONT Price: $774.87 |
| 5 |
44041-007 |
BOLT STRNG STEM HEAD Price: $16.04 |
| 6 |
44043-016 |
WASHER STRNG STEM HD Price: $10.99 |
| 7 |
44039-068 |
HEAD,STEERING STEM Price: $118.86 |
| 8 |
44041-065 |
BOLT,FORK TOP Price: $27.12 |
| 9 |
461DA0800 |
WASHER-SPRING,8MM This part replaces 461F0800. Price: $0.40 |
| 10 |
317AA0800 |
NUT-HEX-SMALL,8MM This part replaces 311B0800. Price: $0.68 |
| 11 |
44041-044 |
BOLT-STEERING STEM HD Price: $9.20 |
| 12 |
44010-020 |
DUST SHIELD-STRNG STM Price: $3.57 |
| 13 |
44052-011 |
SHAFT,STEERING STEM Price: $75.19 |
| 14 |
44041-082 |
SCREW,TOP BOLT Price: $4.63 |
| 15 |
44046-024 |
O RING Price: $1.54 |
| 16 |
44032-013 |
BOLT,FORK TOP Price: $21.03 |
| 18 |
44041-040 |
BOLT,SOCKET,FORK CYLINDER Price: $6.57 |
| 19 |
44063-013 |
HOLDER,FORK AXLE Price: $23.10 |
| 20 |
92047-010 |
CONE STERNG BERG LOW Price: $10.51 |
| 21 |
44038-010 |
STEM,STEERING Price: $272.25 |
| 22 |
110N0835 |
BOLT HEX HEAD 8X35 Price: $3.05 |
| 23 |
44041-042 |
BOLT-STEERING STEM HD Price: $5.13 |
| 24 |
461DA1000 |
WASHER-SPRING,10MM This part replaces 461F1000. Price: $0.68 |
| 25 |
311B1000 |
NUT (10MM) Price: $0.55 |
| 26 |
44028-038 |
GUIDE,FORK SPRING Price: $5.69 |
| 27 |
44026-069 |
SPRING,FORK Price: $29.32 |
| 28 |
44013-056 |
TUBE,FORK INNER Price: $126.52 |
| 29 |
44022-036 |
CYLINDER-FORK Price: $59.17 |
| 30 |
44018-010 |
PISTON,FORK Price: $8.85 |
| 31 |
481J2600 |
CIRCLIP,26MM Price: $1.26 |
| 32 |
44010-033 |
DUST SHIELD Price: $24.39 |
| 33 |
44044-022 |
CIRCLIP,FORK OUT TUB Price: $2.58 |
| 34 |
44043-059 |
WASHER Price: $2.42 |
| 35 |
44009-025 |
OIL SEAL Price: $24.39 |
| 36 |
44005-062 |
TUBE,LH,FORK OUTER Price: $184.47 |
| 37 |
44006-060 |
TUBE,RH,FORK OUTER Price: $161.92 |
| 38 |
220AA0408 |
SCREW-PAN-CROS,4X8 This part replaces 220B0408. Price: $0.68 |
| 39 |
44045-002 |
GASKET,FORK DRAIN PLUG Price: $5.18 |
| 40 |
44045-057 |
GASKET,FORK CYLINDER Price: $4.86 |
