| Ref | Part Number | Description |
|---|
| 2 |
EL8-48212-00-00 |
BACK PLATE 1 Price: $10.99 |
| 3 |
EL8-48251-00-00 |
PLATE, CAM Price: $37.75 |
| 4 |
97885-05016-00 |
SCREW, PAN HEAD This part replaces 97890-05016-00. Price: $4.60 |
| 5 |
6X0-48138-00-00 |
CAP, LOCK ARM Price: $14.90 |
| 6 |
93430-06024-00 |
CIRCLIP Price: $3.95 |
| 7 |
92990-10600-00 |
WASHER, PLATE Price: $3.00 |
| 8 |
EL8-48259-00-00 |
CIRCLIP 1 Price: $7.15 |
| 9 |
6X0-48265-00-00 |
SHAFT, FRICTION Price: $17.75 |
| 10 |
6X0-48262-00-00 |
SHAFT, THROTTLE Price: $15.58 |
| 11 |
6X0-48264-00-00 |
THROTTLE, FRICTION Price: $57.20 |
| 12 |
6X0-48187-00-00 |
PLATE, ADJUST Price: $17.75 |
| 13 |
95380-06600-00 |
NUT, HEXAGON Price: $4.80 |
| 14 |
704-48266-00-00 |
SPACER Price: $5.82 |
| 15 |
704-82540-00-00 |
NEUTRAL SWITCH ASSY Price: $39.75 |
| 16 |
703-48129-00-00 |
SCREW 3 Price: $2.00 |
| 17 |
EL8-48281-00-00 |
SCREW 1 Price: $7.70 |
| 18 |
98580-05525-00 |
SCREW, PAN HEAD This part replaces 97890-05025-00. Price: $2.00 |
| 19 |
6X0-48261-00-00 |
ARM, THROTTLE Price: $49.65 |
| 20 |
EL8-48191-00-00 |
WASHER 1 Price: $3.35 |
| 21 |
97080-06018-00 |
BOLT This part replaces 97380-06018-00. Price: $8.99 |
| 22 |
703-48345-01-00 |
CABLE END, REMOTE CONTROL 2 Price: $16.25 |
| 23 |
EL8-48271-00-00 |
ARM, SHIFT Price: $12.15 |
| 24 |
EL8-48127-00-00 |
SCREW 1 Price: $6.25 |
| 25 |
703-48358-01-00 |
ANCHOR, CABLE Price: $10.70 |
| 26 |
6X0-48211-00-00 |
HOUSING, 1 Price: $139.50 |
| 27 |
EL8-48231-00-00 |
HOUSING, GEAR Price: $40.20 |
| 28 |
EL8-48241-00-00 |
ARM, DRIVE Price: $36.40 |
| 29 |
EL8-48254-00-00 |
STOPPER, THROTTLE ADJUSTING Price: $17.75 |
| 30 |
98780-06020-00 |
SCREW, FLAT HEAD This part replaces 92780-06020-00. Price: $9.49 |
| 31 |
EL8-48158-00-00 |
SPRING 1 Price: $2.52 |
| 32 |
98580-04006-00 |
SCREW, PAN HEAD Price: $3.20 |
| 33 |
EL8-48244-00-00 |
SPRING, FREE ACCEL. Price: $20.20 |
| 34 |
EL8-48245-00-00 |
PLATE, LOCK Price: $13.75 |
| 35 |
704-48178-00-00 |
PLATE, SHIFT Price: $5.94 |
| 36 |
701-48248-00-00 |
ROLLER, FREE ACCEL. Price: $6.70 |
| 37 |
704-48238-00-00 |
SPRING, DETENT Price: $2.91 |
| 38 |
6X0-48121-00-00 |
GEAR 1 Price: $39.40 |
| 39 |
EL8-48164-00-00 |
PIN 2 Price: $11.82 |
| 40 |
EL8-48242-10-00 |
SHAFT, DRIVE Price: $48.15 |
| 41 |
702-48263-00-00 |
BUSHING 4 Price: $6.80 |
| 42 |
EL8-48279-00-00 |
CIRCLIP 2 Price: $17.10 |
| 43 |
704-48193-00-00 |
WASHER 3 Price: $14.45 |
| 44 |
EL8-48234-00-00 |
BUSHING 1 Price: $7.15 |
| 45 |
703-48192-00-00 |
WASHER 2 Price: $4.80 |
| 46 |
EL8-48233-00-00 |
GEAR 2 Price: $22.15 |
| 47 |
703-48235-00-00 |
BUSHING This part replaces 702-48235-00-00. Price: $11.35 |
| 48 |
6X0-48153-00-00 |
SHAFT, FREE ACCEL. Price: $15.40 |
| 49 |
6X3-48222-10-00 |
GRIP, CONTROL LEVER Price: $23.35 |
| 50 |
703-48227-00-00 |
SPRING, NEUTRAL LOCK Price: $7.15 |
| 51 |
98580-05008-00 |
SCREW, PAN HEAD Price: $8.49 |
| 52 |
6X3-82563-02-00 |
TRIM & TILT SWITCH ASSY Price: $123.10 |
| 53 |
6X0-48288-00-00 |
WASHER, PLAIN Price: $6.70 |
| 54 |
6X0-48127-00-00 |
SCREW 1 Price: $3.20 |
| 55 |
6X0-48223-00-00 |
LOCK, NEUTRAL Price: $29.15 |
| 56 |
6X3-48221-10-00 |
LEVER, CONTROL Price: $169.75 |
| 57 |
6X3-48225-10-00 |
COVER Price: $13.00 |
| 58 |
6X3-48225-00-00 |
COVER Price: $16.05 |
| 59 |
6X3-48111-00-00 |
BODY, REMOTE CONTROL 1 Price: $30.55 |
| 60 |
6X3-48225-30-00 |
COVER Price: $8.99 |
| 61 |
6X0-48155-00-00 |
PLUNGER Price: $20.65 |
| 62 |
92990-05300-00 |
WASHER, INTERNAL TOOTH Price: $9.49 |
| 63 |
6X0-48281-00-00 |
SCREW Price: $3.20 |
| 64 |
6X0-48193-00-00 |
WASHER 3 Price: $14.90 |
| 66 |
6X0-48156-00-00 |
NUT 1 Price: $11.35 |
| 67 |
701-48287-00-00 |
WASHER Price: $10.95 |
| 68 |
6X3-48129-00-00 |
SCREW 3 Price: $6.60 |
| 69 |
6X3-82575-01-00 |
ENGINE STOP SWITCH ASSY Price: $72.05 |
| 70 |
682-82556-00-00 |
LANYARD, STOP SWITCH Price: $8.20 |
| 71 |
704-48281-00-00 |
SCREW 1 Price: $12.55 |
| 72 |
704-82541-10-00 |
WIRE, LEAD Price: $37.75 |
| 73 |
6X0-48116-00-00 |
BUSHING Price: $6.75 |
| 74 |
6X3-44191-00-00 |
INDICATOR, SHIFT Price: $10.70 |
