| Ref | Part Number | Description |
|---|
| 1 |
69G-82105-02-00 |
BATTERY CABLE (L: Price: $139.45 |
| 2 |
69G-82590-01-00 |
WIRE HARNESS ASSY Price: $316.25 |
| 4 |
6G8-82117-01-00 |
WIRE, LEAD Price: $24.45 |
| 5 |
90446-10M86-00 |
HOSE (L140) Price: $4.20 |
| 6 |
68T-81940-00-00 |
STARTER RELAY ASSY Price: $88.75 |
| 7 |
97E95-06610-00 |
BOLT, HEXAGON W/W Price: $1.00 |
| 8 |
68T-81945-01-00 |
PLATE, SWITCH FITTING Price: $11.55 |
| 9 |
97E95-06512-00 |
BOLT, HEXAGON W/W Price: $2.05 |
| 10 |
90465-13M11-00 |
CLAMP Price: $8.49 |
| 11 |
90465-13M11-00 |
CLAMP Price: $8.49 |
| 12 |
68T-86112-00-00 |
STAY, SOLENOID Price: $23.55 |
| 13 |
90480-13018-00 |
GROMMET Price: $9.49 |
| 14 |
97E95-06512-00 |
BOLT, HEXAGON W/W Price: $2.05 |
| 15 |
68T-86111-00-00 |
COIL, SOLENOID Price: $125.60 |
| 16 |
68T-41237-00-00 |
JOINT, LINK Price: $34.15 |
| 17 |
91690-30010-00 |
PIN, SPRING Price: $6.15 |
| 18 |
98580-04008-00 |
SCREW, PAN HEAD This part replaces 97980-04208-00. Price: $6.49 |
| 19 |
68T-86117-00-00 |
HOOK, WIRE PULL Price: $9.65 |
| 20 |
93210-03261-00 |
O-RING Price: $6.85 |
| 21 |
69G-81950-00-00 |
RELAY ASSY Price: $317.15 |
| 22 |
90387-06M03-00 |
COLLAR Price: $10.40 |
| 23 |
90119-06293-00 |
BOLT, WITH WASHER Price: $4.20 |
| 24 |
69G-81948-01-00 |
BRACKET Price: $24.60 |
| 25 |
90109-06M86-00 |
BOLT Price: $1.81 |
| 26 |
69G-81925-00-00 |
TERMINAL Price: $33.85 |
| 27 |
90170-06M30-00 |
NUT Price: $2.55 |
| 28 |
90204-06M00-00 |
WASHER, SPRING Price: $3.15 |
| 29 |
6G5-82119-10-00 |
COVER, LEAD WIRE This part replaces 6G5-82119-00-00. Price: $10.40 |
| 30 |
68T-82150-00-00 |
FUSE HOLDER ASSY Price: $43.00 |
| 31 |
67F-82151-40-00 |
FUSE (10A) This part replaces 66V-82151-00-00. Price: $7.10 |
| 32 |
68T-82171-01-00 |
STAY, FUSE BOX Price: $65.05 |
| 33 |
67F-2812A-00-00 |
PULLER, FUSE Price: $5.55 |
| 34 |
69G-82563-10-00 |
TRIM & TILT SWITCH ASSY Price: $174.65 |
| 35 |
69G-83773-10-00 |
BRACKET, SWITCH Price: $61.00 |
| 36 |
97985-06220-00 |
SCREW, WITH WASHER This part replaces 97980-06220-00. Price: $3.49 |
| 37 |
90179-06M24-00 |
NUT Price: $4.80 |
