| Ref | Part Number | Description |
|---|
| 1 |
311AA0600 |
NUT-HEX,6MM This part replaces 311B0600. Price: $0.96 |
| 2 |
411AA0600 |
WASHER-PLAIN,6MM This part replaces 411B0600. Price: $2.92 |
| 3 |
291H0624 |
SCREW,SLOTTED,6X24 Price: $7.21 |
| 4 |
13102-023 |
INNER,CLUT RELESE Price: $8.20 |
| 5 |
13104-017 |
INNER,CLUTCH RELEASE Price: $29.74 |
| 6 |
13118-014 |
OUTER,CLUT RELESE Price: $13.41 |
| 7 |
220AA0614 |
SCREW-PAN-CROS,6X14 This part replaces 220B0614. Price: $1.48 |
| 9 |
92052-010 |
OIL SEAL TB7246 Price: $20.97 |
| 11 |
92022-168 |
WASHER,20.5X34X1.4 Price: $9.51 |
| 12 |
13075-006 |
PINION-KICKSTARTER Price: $64.50 |
| 13 |
13081-084 |
CLUTCH-ASSY Price: $306.20 |
| 14 |
13095-1024 |
HOUSING-COMP-CLUTCH Price: $422.79 |
| 15 |
92028-014 |
BUSH-CLUTCH Price: $21.46 |
| 16 |
13087-032 |
HUB,CLUTCH Price: $66.91 |
| 17 |
13088-1015 |
PLATE-FRICTION Price: $20.55 |
| 18 |
13229-002 |
RING-CLUTCH STEEL Price: $13.58 |
| 19 |
13089-003 |
PLATE CLUTCH STEEL Price: $14.22 |
| 20 |
13187-004 |
PLATE-CLUTCH SPRING Price: $41.41 |
| 21 |
92081-080 |
SPRING-CLUTCH Price: $15.34 |
| 22 |
92022-167 |
WASHER-PLAIN,5MM Price: $2.74 |
| 23 |
92003-078 |
BOLT,5X18 Price: $4.78 |
| 24 |
92024-046 |
WASHER-LOCK,14MM Price: $4.78 |
| 25 |
315AA1400 |
NUT,14MM This part replaces 315B1400. Price: $2.17 |
| 26 |
13116-016 |
PUSHER-CLTCH SPRG PLT Price: $21.08 |
| 27 |
92081-096 |
SPRING-CLUTCH RELEASE Price: $5.54 |
| 28 |
92022-270 |
WASHER,17.3X30X1.4 Price: $9.84 |
