| Ref | Part Number | Description |
|---|
| 1 |
16001-1200 |
CARBURETOR Price: $1,215.65 |
| 1 |
16001-1314 |
CARBURETOR Price: $1,530.29 |
| 2 |
16001-1309 |
CARBURETOR,L.H,OUTER Price: $283.44 |
| 3 |
16001-1310 |
CARBURETOR,L.H,INSIDE Price: $296.99 |
| 4 |
16001-1311 |
CARBURETOR,R.H.INSIDE Price: $364.77 |
| 5 |
16001-1312 |
CARBURETOR,R.H.OUTSID Price: $370.74 |
| 6 |
220AA0520 |
SCREW-PAN-CROS This part replaces 220B0520. Price: $0.68 |
| 7 |
461DA0500 |
WASHER-SPRING,5MM This part replaces 461F0500. Price: $0.71 |
| 8 |
16041-1017 |
SHAFT,CHOKE LINK Price: $43.33 |
| 9 |
92140-1004 |
BALL,STEEL,3/16" Price: $1.51 |
| 10 |
92081-1619 |
SPRING,SHAFT STOP This part replaces 92081-1249. Price: $7.55 |
| 11 |
92009-1096 |
SCREW,LINK SHAFT Price: $8.54 |
| 12 |
92081-1262 |
SPRING,WAVED WASHER Price: $3.83 |
| 13 |
92022-1204 |
WASHER Price: $4.43 |
| 14 |
92022-1199 |
WASHER,6.1X11X0.8,POLYACETAL Price: $4.60 |
| 15 |
92022-1200 |
WASHER,6.4X9.4X0.8,PL Price: $4.37 |
| 16 |
311AA0500 |
NUT-HEX,5MM This part replaces 311B0500. Price: $0.47 |
| 17 |
92022-1201 |
WASHER,LOCK,5M/M Price: $3.77 |
| 18 |
461DA0500 |
WASHER-SPRING,5MM This part replaces 461F0500. Price: $0.71 |
| 19 |
13168-1065 |
LEVER,CHOKE Price: $14.57 |
| 20 |
11034-1800 |
PLATE,CARBURETOR STAY Price: $57.49 |
| 21 |
223AA0616 |
SCREW-PAN-WS-CROS,6X1 This part replaces 92009-1129. Price: $5.38 |
| 22 |
92081-1250 |
SPRING Price: $6.17 |
| 23 |
92005-1026 |
FITTING,FUEL TUBE Price: $47.19 |
| 24 |
92055-1004 |
RING-O Price: $4.31 |
| 25 |
13091-1078 |
HOLDER,ADJUST Price: $11.88 |
| 26 |
92001-1328 |
BOLT,HEX HEAD,5X70 Price: $10.10 |
| 27 |
92022-1203 |
WASHER Price: $5.45 |
| 28 |
92081-1251 |
SPRING Price: $4.71 |
| 29 |
16021-1027 |
SCREW,SLOTTED Price: $20.10 |
| 30 |
92015-1118 |
NUT,5M/M Price: $8.79 |
| 31 |
92081-1252 |
SPRING Price: $4.71 |
| 32 |
92059-1029 |
TUBE,FUEL INLET Price: $30.56 |
| 33 |
92037-1075 |
CLAMP,FUEL TUBE Price: $3.96 |
| 34 |
92059-1139 |
TUBE,5.3X10.5X160 This part replaces 92059-1001. Price: $14.90 |
| 35 |
92037-1682 |
CLAMP,TUBE Price: $6.15 |
| 36 |
92059-1748 |
TUBE,3.5X6.5X420 This part replaces 92059-1140. Price: $23.25 |
| 37 |
11012-1130 |
TUBE,DUST SEAL Price: $3.77 |
| 38 |
92037-1201 |
CLAMP Price: $4.60 |
| 39 |
11034-1799 |
BRACKET,THROTTLE CABL Price: $17.06 |
| 40 |
11065-0282 |
CAP This part replaces 11012-1129. Price: $7.28 |
| 41 |
92022-1207 |
WASHER,6.5X11X1.2,STL Price: $4.37 |
| 42 |
92005-1027 |
NIPPLE,FUEL Price: $14.66 |
| 43 |
92059-1148 |
TUBE,4.5X8X180 Price: $12.58 |
