| Ref | Part Number | Description |
|---|
| 10 |
520001481 |
Snow Gard Price: $104.99 |
| 40 |
516008738 |
BRP Logo 48mm Price: $16.99 |
| 60 |
520001487 |
Light Fairing Price: $20.99 |
| 130 |
130BA0610 |
BOLT-FLANGED,6X10 Price: $1.20 |
| 130A |
130BB0610 |
BOLT-FLANGED,6X10 Price: $2.49 |
| 130B |
130BB0612 |
BOLT-FLANGED,6X12 Price: $2.34 |
| 200 |
520001143 |
Rear Light Price: $104.99 |
| 205 |
250000725 |
Screw M4 X 16 Price: $3.59 |
| 218 |
390402200 |
Pop Rivet 3/16" Price: $0.35 |
| 220 |
520002921 |
Extruded Trim This part replaces 520001719. Price: $22.49 |
| 225 |
520002930 |
Grommet This part replaces 520001703. Price: $21.99 |
| 230 |
520001722 |
Cap Price: $11.49 |
| 235 |
293150104 |
Pop Rivet 3/16" Price: $1.09 |
| 400 |
520001900 |
Red, RH Rear Reflector Price: $19.99 |
| 410 |
520001901 |
Red, LH Rear Reflector Price: $19.99 |
| 1000 |
520002343 |
RH Front Reflector This part replaces 520001493. Price: $9.39 |
| 1010 |
520002344 |
LH Front Reflector This part replaces 520001494. Price: $11.99 |
| 1400a |
529017500 |
Rope Starter Price: $1.19 |
| 2300 |
516008594 |
LH Safety Label Price: $0.01 |
| 2400 |
516006892 |
RH English Warning Decal Price: $0.01 |
| 3400 |
520001897 |
Operator Guide English Price: $9.99 |
| 9510 |
293150104 |
Pop Rivet 3/16" Price: $1.09 |
| 9520 |
517124300 |
Washer Price: $0.19 |
| 26006 |
26006-0001 |
FUSE,MINI BLADE,15A,BLUE Price: $6.12 |
| 26006A |
26006-1078 |
FUSE,MINI BLADE,10A,RED Price: $4.87 |
| 26011 |
26011-0089 |
WIRE-LEAD,BATTERY(+) Price: $46.79 |
| 26011A |
26011-0090 |
WIRE-LEAD,BATTERY(-) Price: $31.86 |
| 26011B |
26011-0271 |
WIRE-LEAD,CAP Price: $14.74 |
| 26012 |
26012-1253 |
YTX12-BS 0.59L This part replaces 26012-0094. Price: $119.64 |
| 26031 |
26031-0448 |
HARNESS,RR Price: $66.68 |
| 26031A |
26031-0962 |
HARNESS,MAIN Price: $654.84 |
| 27002 |
27002-0050 |
RELAY-ASSY This part replaces 27002-0025. Price: $143.14 |
| 27002A |
27002-1101 |
RELAY-ASSY,TURN SIGNAL Price: $72.36 |
| 27003 |
27003-0039 |
HORN Price: $63.70 |
| 56030 |
56030-0016 |
LABEL,FUSE BOX Price: $6.12 |
| 56030A |
56030-0046 |
LABEL,FUSE BOX Price: $5.87 |
| 92037 |
92037-1827 |
CLAMP,HOSE Price: $7.45 |
| 92160 |
92160-1635 |
DAMPER,BATTERY Price: $28.40 |
| 92161 |
92161-0203 |
DAMPER,RELAY BOX Price: $10.37 |
| 92171 |
92171-0081 |
CLAMP,20MM DIA. Price: $4.18 |
| 92171A |
92171-0347 |
CLAMP,CABLE Price: $5.57 |
