| Ref | Part Number | Description |
|---|
| 130 |
130BA0630 |
BOLT-FLANGED,6X30 This part replaces 130H0630. Price: $1.46 |
| 130A |
130BB0820 |
BOLT-FLANGED,8X20 This part replaces 130J0820. Price: $0.84 |
| 130B |
130BB0850 |
BOLT-FLANGED,8X50 This part replaces 130J0850. Price: $4.73 |
| 220 |
220AB0610 |
SCREW-PAN-CROS,6X10 This part replaces 220F0610. Price: $1.81 |
| 11012 |
11012-1784 |
CAP Price: $6.32 |
| 13107 |
13107-0001 |
SHAFT Price: $71.54 |
| 13168 |
13168-7501 |
LEVER Price: $22.02 |
| 13271 |
13271-0099-B9 |
PLATE,CARRIER,SIDE,LH Price: $215.26 |
| 13271A |
13271-0099-467 |
PLATE,CARRIER,SIDE,LH Price: $243.96 |
| 13271B |
13271-0100-B9 |
PLATE,CARRIER,SIDE,RH Price: $215.26 |
| 13271C |
13271-0100-467 |
PLATE,CARRIER,SIDE,RH,A.R Price: $258.05 |
| 14090 |
14090-1260 |
COVER,ENCLOSURE,LH Price: $56.95 |
| 14090A |
14090-1261 |
COVER,ENCLOSURE,RH Price: $56.95 |
| 14091 |
14091-1151 |
COVER,SEAT UNDER Price: $77.66 |
| 14091A |
14091-1152 |
COVER,SEAT REAR Price: $56.13 |
| 27012A |
27012-0022 |
HOOK,TAIL GATE This part replaces 27012-1406. Price: $6.43 |
| 35011 |
35011-1648 |
STAY,CARRIER STOPPER Price: $28.90 |
| 39156 |
39156-0007 |
PAD,ENCLOSURE COVER,L Price: $39.91 |
| 39156A |
39156-0008 |
PAD,ENCLOSURE COVER,R Price: $40.64 |
| 39156B |
39156-0009 |
PAD,SEAT UNDER Price: $46.81 |
| 39156C |
39156-0010 |
PAD,CARRIER,MIDDLE Price: $75.13 |
| 39156D |
39156-0011 |
PAD,SEAT REAR Price: $23.46 |
| 39156E |
39156-0012 |
PAD,CARRIER,FR Price: $37.09 |
| 39156F |
39156-0013 |
PAD,CARRIER,RR Price: $80.35 |
| 53004 |
53004-0003 |
MAT,CARRIER,FR Price: $67.53 |
| 53004A |
53004-0036 |
MAT,CARRIER,MIDDLE This part replaces 53004-0004. Price: $24.70 |
| 53004B |
53004-0037 |
MAT,CARRIER,RR This part replaces 53004-0005. Price: $17.03 |
| 53029 |
53029-0006-B9 |
CARRIER,H.GREEN Price: $1,061.76 |
| 53029A |
53029-0006-467 |
CARRIER,A.RED Price: $987.31 |
| 53045 |
53045-0031 |
HOOK-ASSY,TAIL GATE This part replaces 53045-0004. Price: $29.74 |
| 53062 |
53062-0001-B9 |
GATE-TAIL,H.GREEN Price: $444.42 |
| 53062A |
53062-0001-467 |
GATE-TAIL,A.RED Price: $444.42 |
| 92009 |
92009-1694 |
SCREW,6X16 This part replaces 92009-1621. Price: $3.92 |
| 92015 |
92210-0004 |
NUT,FLANGED,8MM This part replaces 92015-1408. Price: $5.38 |
| 92015A |
92015-1675 |
NUT,LOCK,FLANGED,6MM Price: $4.31 |
| 92022 |
92022-1545 |
WASHER,7X18X1.2 Price: $1.03 |
| 92043 |
92043-1428 |
PIN,12X65 Price: $10.09 |
| 92075 |
92075-1817 |
DAMPER Price: $6.22 |
| 92075A |
92075-1882 |
DAMPER Price: $8.10 |
| 92145 |
92145-1215 |
SPRING,TENSIONER Price: $4.63 |
| 92161 |
92161-0258 |
DAMPER This part replaces 92161-0083. Price: $4.16 |
| 92190 |
92190-1401 |
TUBE,13X16X200 Price: $5.25 |
| 92190A |
92190-1467 |
TUBE,8X10X15 Price: $3.89 |
