| Ref | Part Number | Description |
|---|
| 1 |
18071-003 |
SPRING-CONNECTOR Price: $11.49 |
| 2 |
18002-117 |
MUFFLER ASSY Price: $408.65 |
| 3 |
18033-082 |
BAFFLE TUBE Price: $31.87 |
| 4 |
464H0600 |
WASHER LOCK 6MM Price: $0.68 |
| 5 |
112BA0612 |
BOLT-UPSET This part replaces 112G0612. Price: $1.49 |
| 6 |
18071-006 |
SPRING,MUFFLER Price: $10.99 |
| 7 |
18024-022 |
BRACKET,MUFFLER Price: $36.07 |
| 8 |
110N0835 |
BOLT HEX HEAD 8X35 Price: $3.05 |
| 9 |
461DA0800 |
WASHER-SPRING,8MM This part replaces 461F0800. Price: $0.40 |
| 10 |
92019-018 |
NUT,8MM Price: $7.24 |
| 11 |
411AA1200 |
WASHER-PLAIN,12MM This part replaces 411B1200. Price: $0.96 |
| 12 |
220AA0620 |
SCREW-PAN-CROS,6X20 This part replaces 220B0620. Price: $5.82 |
| 13 |
461DA0600 |
WASHER-SPRING,6MM This part replaces 461F0600. Price: $0.71 |
| 14 |
92022-024 |
WASHER,7X16X1.2 Price: $3.65 |
| 15 |
92075-076 |
DAMPER RUBBER Price: $4.78 |
| 16 |
92027-194 |
COLLAR,L=11.1 Price: $5.52 |
| 17 |
11011-037 |
BODY,AIR CLEANER Price: $152.24 |
| 18 |
92075-107 |
DAMPER RUBBER Price: $3.99 |
| 19 |
11010-075 |
AIR CLEANER ASSY Price: $114.02 |
| 20 |
92019-019 |
NUT,6MM Price: $9.48 |
| 21 |
461DA0600 |
WASHER-SPRING,6MM This part replaces 461F0600. Price: $0.71 |
| 22 |
411AA0600 |
WASHER-PLAIN,6MM This part replaces 411B0600. Price: $2.92 |
| 23 |
11012-035 |
CAP,AIR CLEANER Price: $10.03 |
| 24 |
11013-041 |
ELEMENT,AIR,CLNR Price: $44.01 |
| 25 |
11026-011 |
CONNECTOR Price: $28.90 |
| 26 |
11012-044 |
CAP,CONNECTOR Price: $7.16 |
| 27 |
220AA0616 |
SCREW-PAN-CROS,6X16 This part replaces 220B0616. Price: $3.04 |
| 28 |
220AA0535 |
SCREW-PAN-CROS This part replaces 220B0535. Price: $3.70 |
| 29 |
92037-106 |
CLAMP Price: $17.78 |
| 30 |
11015-044 |
INLET PIPE Price: $81.83 |
| 31 |
11017-012 |
GASKET,INLET PIPE Price: $5.45 |
| 32 |
92067-019 |
PLUG,AIR CLEANER BODY Price: $3.57 |
