| Ref | Part Number | Description |
|---|
| 1 |
6AW-W8195-10-00 |
RELAY ASSY This part replaces 6AW-81950-00-00. Price: $314.75 |
| 2 |
97E95-06610-00 |
BOLT, HEXAGON W/W Price: $1.00 |
| 3 |
97513-06520-00 |
BOLT, WITH WASHER Price: $1.95 |
| 4 |
6G5-82119-10-00 |
COVER, LEAD WIRE Price: $10.40 |
| 5 |
6AW-8194A-00-00 |
RELAY Price: $71.70 |
| 6 |
68V-81953-00-00 |
STAY, RELAY Price: $5.55 |
| 7 |
97780-60520-00 |
SCREW, TAPPING This part replaces 97780-60620-00. Price: $4.49 |
| 8 |
97E95-06610-00 |
BOLT, HEXAGON W/W Price: $1.00 |
| 9 |
6G5-82119-10-00 |
COVER, LEAD WIRE This part replaces 6G5-82119-00-00. Price: $10.40 |
| 10 |
6AW-81952-00-00 |
HOLDER, RELAY Price: $21.65 |
| 11 |
90464-12183-00 |
CLAMP Price: $3.50 |
| 12 |
90464-11121-00 |
CLAMP Price: $3.20 |
| 13 |
6A0-82317-01-00 |
DAMPER, IGNITION C This part replaces 6A0-82317-00-00. Price: $7.10 |
| 14 |
90387-06119-00 |
COLLAR Price: $4.80 |
| 15 |
90119-06289-00 |
BOLT, WITH WASHER This part replaces 90119-06M59-00. Price: $3.65 |
| 16 |
6AW-81942-00-00 |
COVER Price: $52.65 |
| 17 |
95D95-06016-00 |
BOLT, FLANGE DEEP Price: $0.95 |
| 18 |
6AW-82170-03-00 |
FUSE BOX ASSY Price: $524.45 |
| 19 |
6P2-82151-00-00 |
FUSE (60A) Price: $12.10 |
| 20 |
6AW-8195A-00-00 |
RELAY ASSY Price: $62.15 |
| 21 |
67F-82151-40-00 |
FUSE (10A) Price: $7.10 |
| 22 |
67F-82151-50-00 |
FUSE (15A) Price: $4.05 |
| 23 |
5JJ-82151-20-00 |
FUSE (20A-BL) This part replaces 67F-82151-00-00. Price: $8.49 |
| 24 |
5JJ-82151-60-00 |
FUSE This part replaces 67F-82151-10-00. Price: $8.49 |
| 25 |
6P2-85544-00-00 |
CASE Price: $32.60 |
| 26 |
6P2-81639-10-00 |
COVER Price: $8.25 |
| 27 |
68F-82846-00-00 |
SCREW, PAN HEAD (M5) Price: $5.50 |
| 28 |
6P2-82113-00-00 |
SCREW (M3) Price: $3.65 |
| 29 |
67F-2812A-00-00 |
PULLER, FUSE Price: $5.55 |
| 30 |
97780-50620-00 |
SCREW, TAPPING Price: $3.20 |
| 31 |
6AW-82171-00-00 |
STAY, FUSE BOX Price: $22.55 |
| 32 |
6A0-82317-01-00 |
DAMPER, IGNITION C This part replaces 6A0-82317-00-00. Price: $7.10 |
| 33 |
90387-06119-00 |
COLLAR Price: $4.80 |
| 34 |
90119-06289-00 |
BOLT, WITH WASHER This part replaces 90119-06M59-00. Price: $3.65 |
| 35 |
6AW-82572-00-00 |
GROMMET 1 Price: $12.00 |
| 36 |
6AW-82573-00-00 |
GROMMET 2 Price: $11.80 |
| 37 |
6AW-81948-00-00 |
BRACKET Price: $185.25 |
| 38 |
95D95-06020-00 |
BOLT, FLANGE DEEP Price: $5.35 |
| 39 |
6AW-81678-00-00 |
CLAMP 2 Price: $29.40 |
| 40 |
90464-11121-00 |
CLAMP Price: $3.20 |
| 41 |
6AW-81443-00-00 |
CLAMP, LEAD 1 Price: $13.35 |
| 42 |
97780-50514-00 |
SCREW, TAPPING Price: $4.15 |
| 43 |
90465-10098-00 |
CLAMP This part replaces 90465-11M10-00. Price: $2.70 |
| 44 |
90464-09008-00 |
CLAMP Price: $3.20 |
| 45 |
6AW-81919-20-00 |
GRAPHIC, REGULATOR Price: $4.85 |
