| Ref | Part Number | Description |
|---|
| 1 |
6AH-85540-00-00 |
C.D.I. UNIT ASSY Price: $417.90 |
| 2 |
97E95-06520-00 |
BOLT, HEXAGON W/W Price: $3.05 |
| 3 |
97D95-06030-00 |
BOLT, HEXAGON DEEP Price: $0.95 |
| 4 |
90387-06M74-00 |
COLLAR Price: $16.49 |
| 5 |
6AH-81948-00-00 |
BRACKET Price: $41.65 |
| 6 |
90465-13M18-00 |
CLAMP Price: $1.85 |
| 7 |
90119-06311-00 |
BOLT, WITH WASHER Price: $1.99 |
| 8 |
90387-06289-00 |
COLLAR Price: $3.18 |
| 9 |
90480-10M23-00 |
GROMMET Price: $9.65 |
| 10 |
6AH-82522-00-00 |
CLAMP, COUPLER Price: $21.50 |
| 11 |
98580-06010-00 |
SCREW, PAN HEAD (92503-06010-00 This part replaces 97880-06010-00. Price: $9.49 |
| 12 |
90201-06M08-00 |
WASHER, PLATE This part replaces 90201-06M05-00. Price: $2.50 |
| 13 |
6F5-85570-13-00 |
IGNITION COIL ASSY Price: $121.35 |
| 14 |
90480-25003-00 |
GROMMET Price: $5.50 |
| 15 |
67F-82361-00-00 |
CLAMP, CORD Price: $3.20 |
| 16 |
97E95-06525-00 |
BOLT, HEXAGON W/W Price: $1.00 |
| 17 |
6AH-82370-00-00 |
PLUG CAP ASSY Price: $79.65 |
| 18 |
97E95-06514-00 |
BOLT, HEXAGON W/W Price: $1.25 |
| 19 |
6AH-85542-00-00 |
BRACKET Price: $37.35 |
| 20 |
90464-07M56-00 |
CLAMP Price: $3.40 |
| 21 |
64J-82504-00-00 |
OIL PRESSURE SWITCH ASSY Price: $33.30 |
| 22 |
62Y-84301-00-00 |
PILOT LIGHT ASSY 1 Price: $76.05 |
| 23 |
6FM-83589-00-00 |
GASKET Price: $3.55 |
| 24 |
97885-06012-00 |
SCREW, PAN HEAD This part replaces 97985-06212-00. Price: $3.35 |
| 25 |
6AH-82388-00-00 |
PLATE Price: $4.50 |
| 26 |
90109-06M86-00 |
BOLT Price: $1.81 |
| 27 |
6AH-82560-00-00 |
THERMO SWITCH ASSY Price: $71.10 |
| 28 |
6AH-82588-00-00 |
PLATE Price: $4.50 |
| 29 |
97E95-06514-00 |
BOLT, HEXAGON W/W Price: $1.25 |
| 30 |
6AH-82540-01-00 |
NEUTRAL SWITCH ASSY Price: $139.00 |
| 30 |
6AH-82554-00-00 |
STAY, NEUTRAL SWITCH Price: $56.85 |
| 31 |
97E95-06516-00 |
BOLT, HEXAGON W/W Price: $4.20 |
| 32 |
90464-18246-00 |
CLAMP Price: $2.44 |
| 33 |
90465-13M18-00 |
CLAMP Price: $1.85 |
| 34 |
90464-10M32-00 |
CLAMP Price: $4.50 |
| 35 |
68T-81870-00-00 |
STARTING SWITCH ASSY Price: $53.60 |
| 35 |
6G1-42725-01-00 |
GROMMET Price: $10.70 |
| 36 |
90464-16003-00 |
CLAMP Price: $7.60 |
| 37 |
6AH-82389-00-00 |
PLATE 2 Price: $33.75 |
| 38 |
90109-06M86-00 |
BOLT Price: $1.81 |
| 39 |
6AH-82553-02-00 |
EXTENSION, WIRE LEAD Price: $10.65 |
