| Ref | Part Number | Description |
|---|
| 132 |
132BB0612 |
BOLT-FLANGED-SMALL,6X12 This part replaces 132J0612. Price: $2.06 |
| 11009 |
11009-1127 |
GASKET,FORK CYLINDER BOLT Price: $5.18 |
| 16126 |
16126-1052 |
VALVE AIR Price: $35.06 |
| 44005A |
44005-0011 |
PIPE-LEFT FORK OUTER This part replaces 44005-1335. Price: $518.31 |
| 44006A |
44006-0011 |
PIPE-RIGHT FORK OUTER This part replaces 44006-1333. Price: $518.31 |
| 44013 |
44013-1264 |
PIPE-FORK INNER Price: $421.10 |
| 44022 |
44022-1211 |
CYLINDER-FORK Price: $189.81 |
| 44026 |
44026-1369 |
SPRING-FRONT FORK Price: $72.91 |
| 44028 |
44028-1003 |
GUIDE-FORK SPRING Price: $11.28 |
| 44029 |
44029-1042 |
SEAT-FORK SPRING Price: $72.14 |
| 44037 |
44037-1207 |
HOLDER-FORK UNDER Price: $621.65 |
| 44039 |
44039-1160 |
HOLDER-FORK UPPER Price: $316.18 |
| 44045 |
44045-002 |
GASKET,FORK DRAIN PLUG Price: $5.18 |
| 44065 |
92028-1126 |
BUSHING,FORK PIPE This part replaces 44065-1057. Price: $49.26 |
| 44070 |
44075-5004 |
DAMPER-SET-FORK This part replaces 44070-5141. Price: $1,146.62 |
| 49006A |
49006-1222-4Y |
BOOT,FORK,S.M.BROWN Price: $88.33 |
| 56040 |
56040-1120 |
LABEL,FRONT FORK Price: $6.10 |
| 92001 |
92001-1309 |
BOLT,FORK CYLINDER Price: $7.62 |
| 92002 |
92002-1158 |
BOLT,FLANGED,8X55 Price: $9.23 |
| 92002A |
92002-1982 |
BOLT Price: $5.18 |
| 92002B |
92002-1983 |
BOLT Price: $19.43 |
| 92009 |
92009-1348 |
SCREW Price: $5.18 |
| 92015 |
92210-0004 |
NUT,FLANGED,8MM This part replaces 92015-1408. Price: $5.38 |
| 92022 |
92022-1262 |
WASHER,FORK OUTER PIPE This part replaces 92022-1242. Price: $8.60 |
| 92026 |
92026-1294 |
SPACER Price: $43.78 |
| 92028 |
44065-1091 |
BUSHING-FRONT FORK,OU This part replaces 92028-1125. Price: $25.96 |
| 92033 |
92033-1047 |
RING-SNAP,FORK Price: $6.46 |
| 92037 |
92037-1897 |
CLAMP,HOSE Price: $15.89 |
| 92037A |
92037-1898 |
CLAMP,HOSE Price: $8.58 |
| 92037B |
92037-1913 |
CLAMP Price: $20.72 |
| 92037C |
92037-1931 |
CLAMP Price: $10.42 |
| 92049 |
92049-1180 |
SEAL-OIL,FRONT FORK Price: $22.14 |
| 92072 |
92037-1321 |
CLAMP, BOOT, BLACK This part replaces 92072-1171. Price: $9.52 |
| 92072A |
92072-1225 |
BAND,CABLE Price: $23.47 |
| 92093 |
92093-1166 |
SEAL,FRONT FORK Price: $18.22 |
| 92143 |
92143-1134 |
COLLAR Price: $12.78 |
