| Ref | Part Number | Description |
|---|
| 130 |
130AA0620 |
BOLT-FLANGED,6X20 Price: $1.74 |
| 318 |
318BA0800 |
NUT-HEX-SMALL,8MM Price: $1.34 |
| 33001 |
33001-0129-11E |
ARM-COMP-SWING,F.S.BL Price: $1,112.89 |
| 33032 |
33032-0046 |
SHAFT-SWING ARM This part replaces 33032-0005. Price: $131.48 |
| 33040 |
33040-0017 |
ADJUSTER-CHAIN,LH Price: $41.57 |
| 33040A |
33040-0018 |
ADJUSTER-CHAIN,RH Price: $30.48 |
| 42036 |
42036-1264 |
SLEEVE,SWING ARM,L=237 Price: $66.54 |
| 55020 |
55020-0903 |
GUARD,CHAIN This part replaces 55020-0330. Price: $74.82 |
| 92001 |
92001-1771 |
BOLT,6X12 Price: $3.92 |
| 92015 |
92015-1724 |
NUT,FLANGED,20MM Price: $14.90 |
| 92033 |
92033-1041 |
RING-SNAP,42MM Price: $6.16 |
| 92045 |
92045-0017 |
BEARING-BALL,6004UL11 Price: $14.39 |
| 92046 |
92046-0008 |
BEARING-NEEDLE,7E-HVS 28X34X17 Price: $21.54 |
| 92049 |
92049-1181 |
SEAL-OIL,28X34X5.7 Price: $9.28 |
| 92049A |
92049-1380 |
SEAL-OIL,MHA 35 42 5.7F Price: $13.08 |
| 92152 |
92152-0136 |
COLLAR,SWING ARM PIVO Price: $37.99 |
| 92153 |
92153-1407 |
BOLT,8X55 Price: $2.15 |
| 92171 |
92171-0907 |
CLAMP Price: $10.30 |
| 92171A |
92171-0967 |
CLAMP,DRAIN HOSE Price: $23.53 |
| 92210 |
92210-1347 |
NUT,M28X1.0 Price: $21.63 |
