| Ref | Part Number | Description |
|---|
| 110 |
112BA0660 |
BOLT-UPSET This part replaces 112G0660. Price: $4.53 |
| 120 |
120CA0812 |
BOLT-SOCKET,8X12 This part replaces 120P0812. Price: $4.54 |
| 461 |
461DA0600 |
WASHER-SPRING,6MM This part replaces 461F0600. Price: $0.71 |
| 11009 |
21166-003 |
GASKET,STARTER COVER Price: $15.40 |
| 12046 |
12046-1032 |
SPROCKET,STARTER,58T Price: $104.98 |
| 13107 |
21143-003 |
SHAFT,IDLE GEAR Price: $14.64 |
| 13194 |
13193-1062 |
CLUTCH-ASSY-ONEWAY This part replaces 13193-1012. Price: $186.82 |
| 14025 |
21165-003 |
COVER,STARTER Price: $22.96 |
| 21039 |
21039-1053 |
BRUSH,CARBON Price: $94.23 |
| 21040 |
21040-1003 |
SPRING-BRUSH Price: $9.41 |
| 21053 |
59051-1401 |
GEAR-SPUR This part replaces 21053-004. Price: $93.28 |
| 21163 |
21163-1190 |
STARTER-ELECTRIC Price: $596.26 |
| 26011 |
26011-1081 |
WIRE,STARTER MOTOR Price: $37.24 |
| 27010 |
21164-005 |
SWITCH ASSY,MAGNETIC Price: $159.50 |
| 59051 |
21167-004 |
GEAR,IDLE,29T Price: $101.58 |
| 92001 |
92001-1151 |
BOLT,6X10 Price: $5.01 |
| 92009 |
21099-006 |
SCREW,PAN HEAD,6X130 Price: $8.31 |
| 92015 |
92210-0630 |
NUT,FLANGED,6MM This part replaces 92015-1078. Price: $2.00 |
| 92015A |
92017-014 |
NUT,LOCK 6MM Price: $7.51 |
| 92022 |
21025-011 |
WASHER,9.1X18X0.2 Price: $6.22 |
| 92022A |
92022-1132 |
WASHER,9.1X18X0.8 Price: $6.22 |
| 92026 |
92026-1025 |
SPACER,25X36X3.2 Price: $6.16 |
| 92033 |
92033-1326 |
RING-SNAP This part replaces 92033-034. Price: $10.44 |
| 92033A |
92033-037 |
CIRCLIP,13M/M Price: $9.80 |
| 92043 |
92043-087 |
PIN Price: $12.76 |
| 92046 |
92046-056 |
BRG,NEEDLE,K253017 Price: $23.42 |
| 92055 |
92055-1669 |
RING-O This part replaces 21027-008. Price: $12.48 |
| 92071 |
21017-017 |
GROMMET,STARTER TERMINAL Price: $9.43 |
| 92075 |
92161-1722 |
DAMPER,MAGNETIC SWITCH This part replaces 21064-002. Price: $19.64 |
| 92081 |
92081-110 |
SPRING Price: $4.76 |
| 92122 |
92122-004 |
ROLLER Price: $11.07 |
