| Ref | Part Number | Description |
|---|
| 1 |
6C5-43111-02-8D |
BRACKET, CLAMP 1 This part replaces 6C5-43111-00-8D. Price: $279.15 |
| 2 |
6C5-43112-01-8D |
BRACKET, CLAMP 2 This part replaces 6C5-43112-00-8D. Price: $332.40 |
| 3 |
6E5-82148-00-00 |
WIRE, LEAD 4 Price: $22.90 |
| 4 |
97885-06008-00 |
SCREW, PAN HEAD Price: $1.15 |
| 5 |
65W-45251-00-00 |
ANODE Price: $12.75 |
| 6 |
90101-06020-00 |
BOLT Price: $3.95 |
| 7 |
65W-45251-00-00 |
ANODE Price: $12.75 |
| 8 |
90101-06020-00 |
BOLT Price: $3.95 |
| 9 |
6C5-43311-01-8D |
BRACKET, SWIVEL 1 This part replaces 6C5-43311-00-8D. Price: $542.35 |
| 10 |
93700-06M03-00 |
NIPPLE, GREASE Price: $8.25 |
| 11 |
63D-43131-01-00 |
BOLT, CLAMP BRACKET This part replaces 63D-43131-10-00. Price: $106.20 |
| 12 |
90386-22MA4-00 |
BUSH Price: $9.10 |
| 13 |
90185-22007-00 |
NUT, SELF-LOCKING Price: $23.95 |
| 14 |
6C5-43181-00-00 |
LEVER, TILT STOP 1 This part replaces 6C5-43181-10-00. Price: $64.30 |
| 15 |
6C5-43185-00-00 |
LEVER, TILT STOP 2 This part replaces 6C5-43185-10-00. Price: $77.20 |
| 16 |
90386-10M16-00 |
BUSH Price: $5.55 |
| 17 |
90386-10025-00 |
BUSH Price: $12.55 |
| 18 |
91690-30020-00 |
PIN, SPRING Price: $3.55 |
| 19 |
6G5-43148-00-00 |
COLLAR, DISTANCE Price: $9.45 |
| 20 |
90249-06M19-00 |
PIN Price: $9.10 |
| 21 |
90506-14M24-00 |
SPRING, TENSION Price: $9.10 |
| 22 |
97085-06010-00 |
BOLT This part replaces 97095-06010-00. Price: $1.49 |
| 23 |
6G5-43144-00-00 |
HOOK, SPRING Price: $7.15 |
| 24 |
65W-45251-00-00 |
ANODE Price: $12.75 |
| 25 |
90101-06020-00 |
BOLT Price: $3.95 |
| 26 |
6E5-43126-02-00 |
PIN, UPPER SHOCK MOUNT Price: $54.05 |
| 27 |
90386-18M92-00 |
BUSH Price: $7.15 |
| 28 |
90386-18M35-00 |
BUSH Price: $15.65 |
| 29 |
93410-18M05-00 |
CIRCLIP This part replaces 93410-18M02-00. Price: $5.65 |
| 30 |
63D-83672-12-00 |
TRIM SENDER This part replaces 63D-83672-10-00. Price: $325.99 |
| 31 |
98580-06016-00 |
SCREW, PAN HEAD This part replaces 97885-06016-00. Price: $3.35 |
| 32 |
90464-76001-00 |
CLAMP Price: $6.75 |
| 33 |
90465-10098-00 |
CLAMP This part replaces 90465-11M10-00. Price: $2.70 |
| 34 |
90447-19009-00 |
TUBE Price: $4.65 |
| 35 |
99999-03987-00 |
PIN, LOWER SHOCK MOU This part replaces 6C5-43818-00-00. Price: $148.45 |
| 36 |
6C5-43833-00-00 |
PIPE Price: $7.40 |
| 37 |
6C5-43834-00-00 |
PIPE Price: $11.10 |
| 38 |
97080-08020-00 |
BOLT This part replaces 90101-08016-00. Price: $2.91 |
| 39 |
90201-08M14-00 |
WASHER, PLATE This part replaces 90201-08064-00. Price: $6.40 |
| 40 |
90101-12063-00 |
BOLT (L:105MM) This part replaces 90101-12M65-00. Price: $33.25 |
| 41 |
92990-12200-00 |
WASHER, PLAIN This part replaces 92995-12200-00. Price: $9.49 |
| 42 |
90201-12426-00 |
WASHER, PLATE Price: $2.25 |
