| Ref | Part Number | Description |
|---|
| 1 |
114G0836 |
BOLT Price: $8.84 |
| 2 |
461DA0800 |
WASHER-SPRING,8MM This part replaces 461F0800. Price: $0.40 |
| 2 |
461DA1000 |
WASHER-SPRING,10MM This part replaces 461F1000. Price: $0.68 |
| 3 |
314AA1000 |
NUT-HEX-FINE This part replaces 314B1000. Price: $0.68 |
| 4 |
46012-002-80 |
HOLDER,HANDLEBAR,BUFF Price: $29.86 |
| 5 |
46012-1252 |
HOLDER-HANDLE,UPP This part replaces 46012-004. Price: $13.44 |
| 6 |
461DA1000 |
WASHER-SPRING,10MM This part replaces 461F1000. Price: $0.68 |
| 7 |
44041-072 |
BOLT,STEERING STEM Price: $23.26 |
| 8 |
44043-056 |
WASHER,STEERING STEM Price: $12.51 |
| 9 |
11012-4004 |
CAP Price: $4.04 |
| 10 |
113B1455 |
BOLT HEX HEAD 14X55 Price: $7.34 |
| 11 |
112B1020 |
BOLT-UPSET,10X20 Price: $3.71 |
| 12 |
461DA1000 |
WASHER-SPRING,10MM This part replaces 461F1000. Price: $0.68 |
| 13 |
32085-4006 |
STOPPER Price: $18.47 |
| 14 |
39007-4003 |
ARM-SUSP Price: $85.94 |
| 15 |
42036-4003 |
SLEEVE,14X20X25.3 Price: $20.88 |
| 16 |
44001-4007-8G |
FRONT FORK,EBONY Price: $222.48 |
| 16 |
44001-4007-8R |
FRONT FORK,RED Price: $220.11 |
| 17 |
44039-4003 |
HOLDER-FORK UPPER Price: $47.97 |
| 18 |
92001-1742 |
BOLT This part replaces 44041-081. Price: $19.67 |
| 19 |
92022-1381 |
WASHER Price: $9.44 |
| 20 |
92019-011 |
NUT-LOCK,14MM Price: $10.86 |
| 21 |
92028-4001 |
BUSHING,SWING ARM Price: $11.20 |
| 22 |
92001-1253 |
BOLT,HEX HEAD 10X40 Price: $7.57 |
| 24 |
45014-4010-8G |
SHOCKABSORBER,EBONY Price: $122.39 |
| 25 |
92027-4023 |
COLLAR Price: $3.15 |
| 26 |
92027-4024 |
COLLAR Price: $3.61 |
| 27 |
45017-012 |
DAMPER,SHOCKABSORBER This part replaces 92075-4030. Price: $14.90 |
| 28 |
92001-4018 |
BOLT,12X45 Price: $6.41 |
| 29 |
92210-1373 |
NUT,LOCK,12MM This part replaces 92019-009. Price: $7.29 |
| 30 |
92210-1184 |
NUT,LOCK,10MM This part replaces 92019-021. Price: $6.11 |
