| Ref | Part Number | Description |
|---|
| 1 |
92037-194 |
CLAMP Price: $4.05 |
| 2 |
220AA0614 |
SCREW-PAN-CROS,6X14 This part replaces 220B0614. Price: $1.48 |
| 3 |
92037-1049 |
CLAMP,CABLE Price: $3.60 |
| 4 |
21003-1002 |
STATOR ASSY Price: $328.27 |
| 5 |
220AA0625 |
SCREW-PAN-CROS,6X25 This part replaces 220B0625. Price: $2.78 |
| 6 |
92002-1296 |
BOLT,FLANGED,10X40 This part replaces 92001-1201. Price: $10.65 |
| 7 |
92038-001 |
KEY,WOODRUFF Price: $4.96 |
| 9 |
92081-159 |
SPRING,COIL Price: $3.89 |
| 10 |
92043-132 |
PIN Price: $6.22 |
| 11 |
92122-006 |
ROLLER Price: $6.22 |
| 12 |
13194-008 |
CLUTCH,STARTER Price: $178.85 |
| 13 |
120CA0816 |
BOLT-SOCKET,8X16 This part replaces 120P0816. Price: $4.45 |
| 14 |
12046-1107 |
SPROCKET,STARTER CLUT Price: $116.16 |
| 15 |
92057-1009 |
CHAIN,DYNAMO Price: $49.50 |
| 16 |
21163-1238 |
STARTER, ELECTRIC This part replaces 21163-1036. Price: $502.58 |
| 17 |
12046-1004 |
SPROCKET,STARTER MOTO Price: $59.43 |
| 18 |
92033-037 |
CIRCLIP,13M/M Price: $9.80 |
| 21 |
92055-1313 |
RING-O This part replaces 21027-005. Price: $8.66 |
| 22 |
21017-020 |
CAP,STARTING MOTOR Price: $8.42 |
| 23 |
312AA0600 |
NUT-HEX This part replaces 312B0600. Price: $0.73 |
| 24 |
461DA0600 |
WASHER-SPRING,6MM This part replaces 461F0600. Price: $0.71 |
| 25 |
26011-1201 |
WIRE-LEAD,STARTER MOT Price: $48.53 |
| 27 |
21025-010 |
WASHER,THRUST,1.6T Price: $6.30 |
| 28 |
21025-011 |
WASHER,9.1X18X0.2 Price: $6.22 |
| 29 |
21039-004 |
BRUSH CARBON Price: $41.68 |
| 30 |
21040-004 |
SPRING CARBON BRUSH Price: $11.44 |
| 31 |
130BA0625 |
BOLT-FLANGED,6X25 This part replaces 130G0625. Price: $1.20 |
| 32 |
461DA0600 |
WASHER-SPRING,6MM This part replaces 461F0600. Price: $0.71 |
