| Ref | Part Number | Description |
|---|
| 1 |
112BA0660 |
BOLT-UPSET This part replaces 112G0660. Price: $4.53 |
| 2 |
120CA0812 |
BOLT-SOCKET,8X12 This part replaces 120P0812. Price: $4.54 |
| 3 |
13193-1062 |
CLUTCH-ASSY-ONEWAY This part replaces 13193-1012. Price: $186.82 |
| 4 |
92043-087 |
PIN Price: $12.76 |
| 5 |
92081-110 |
SPRING Price: $4.76 |
| 6 |
92122-004 |
ROLLER Price: $11.07 |
| 7 |
21143-003 |
SHAFT,IDLE GEAR Price: $14.64 |
| 8 |
21164-005 |
SWITCH ASSY,MAGNETIC Price: $159.50 |
| 9 |
312AA0600 |
NUT-HEX This part replaces 312B0600. Price: $0.73 |
| 10 |
461DA0600 |
WASHER-SPRING,6MM This part replaces 461F0600. Price: $0.71 |
| 11 |
21099-006 |
SCREW,PAN HEAD,6X130 Price: $8.31 |
| 12 |
92161-1722 |
DAMPER,MAGNETIC SWITCH This part replaces 21064-002. Price: $19.64 |
| 13 |
312AA0600 |
NUT-HEX This part replaces 312B0600. Price: $0.73 |
| 14 |
461DA0600 |
WASHER-SPRING,6MM This part replaces 461F0600. Price: $0.71 |
| 15 |
21165-003 |
COVER,STARTER Price: $22.96 |
| 16 |
21166-003 |
GASKET,STARTER COVER Price: $15.40 |
| 17 |
21167-004 |
GEAR,IDLE,29T Price: $101.58 |
| 18 |
12046-1032 |
SPROCKET,STARTER,58T Price: $104.98 |
| 19 |
482K0200 |
CIRCLIP 12MM Price: $1.63 |
| 20 |
92001-1151 |
BOLT,6X10 Price: $5.01 |
| 21 |
92017-014 |
NUT,LOCK 6MM Price: $7.51 |
| 22 |
92026-1025 |
SPACER,25X36X3.2 Price: $6.16 |
| 23 |
92046-056 |
BRG,NEEDLE,K253017 Price: $23.42 |
| 24 |
21163-1190 |
STARTER-ELECTRIC Price: $596.26 |
| 26 |
21025-011 |
WASHER,9.1X18X0.2 Price: $6.22 |
| 27 |
21025-010 |
WASHER,THRUST,1.6T Price: $6.30 |
| 28 |
21039-003 |
CARBON BRUSH Price: $40.76 |
| 29 |
21040-003 |
SPRING,CARBON BRUSH Price: $8.56 |
| 30 |
92055-1669 |
RING-O This part replaces 21027-008. Price: $12.48 |
| 31 |
92033-1326 |
RING-SNAP This part replaces 92033-034. Price: $10.44 |
| 32 |
59051-1401 |
GEAR-SPUR This part replaces 21053-004. Price: $93.28 |
| 33 |
92033-037 |
CIRCLIP,13M/M Price: $9.80 |
| 34 |
26011-1081 |
WIRE,STARTER MOTOR Price: $37.24 |
