| Ref | Part Number | Description |
|---|
| 1 |
44041-007 |
BOLT STRNG STEM HEAD Price: $16.04 |
| 2 |
44043-016 |
WASHER STRNG STEM HD Price: $10.99 |
| 3 |
44039-035 |
HEAD-STEERING STEM Price: $147.91 |
| 5 |
44044-011 |
CIRCLIP Price: $2.24 |
| 6 |
44013-027 |
TUBE-FORK INNER Price: $142.89 |
| 8 |
44010-006 |
DUST SHIELD FORK Price: $43.93 |
| 9 |
44043-045 |
WASHER-OIL SEAL FIT Price: $4.03 |
| 10 |
92049-1049 |
OIL SEAL Price: $21.20 |
| 11 |
44005-034-80 |
TUBE,LH,FORK OUTER Price: $251.64 |
| 12 |
44062-002 |
CAP Price: $3.08 |
| 13 |
220AA0408 |
SCREW-PAN-CROS,4X8 This part replaces 220B0408. Price: $0.68 |
| 14 |
44045-002 |
GASKET,FORK DRAIN PLUG Price: $5.18 |
| 15 |
172BA0830 |
BOLT-STUD,8X30 This part replaces 172G0830. Price: $2.56 |
| 16 |
44063-002 |
HOLDER-FRONT AXLE Price: $22.76 |
| 17 |
461DA0800 |
WASHER-SPRING,8MM This part replaces 461F0800. Price: $0.40 |
| 18 |
317AA0800 |
NUT-HEX-SMALL,8MM This part replaces 311B0800. Price: $0.68 |
| 19 |
14039-001 |
CAP CARB MOUNT HOLE Price: $4.74 |
| 20 |
44041-035 |
BOLT-FORK TOP Price: $38.08 |
| 25 |
44029-016 |
WASHER-FORK SPRG SEAT Price: $2.29 |
| 27 |
44028-019 |
GUIDE-FORK SPRING Price: $5.70 |
| 30 |
44018-004 |
PISTON-FORK Price: $8.25 |
| 31 |
44044-010 |
CIRCLIP Price: $1.53 |
| 32 |
92002-1838 |
BOLT,FLANGED,8X40 This part replaces 92001-1578. Price: $8.19 |
| 33 |
113B1032 |
BOLT HEX HEAD 10X32 Price: $6.47 |
| 34 |
461DA1000 |
WASHER-SPRING,10MM This part replaces 461F1000. Price: $0.68 |
| 35 |
92047-004 |
CONE LOWER BEARING Price: $16.97 |
| 36 |
92037-108 |
CLAMP Price: $8.79 |
| 37 |
410AA0600 |
WASHER-PLAIN-SMALL This part replaces 410B0600. Price: $1.31 |
| 38 |
112BA0610 |
BOLT-UPSET,6X10 This part replaces 112G0610. Price: $0.58 |
| 39 |
112BA0618 |
BOLT-UPSET This part replaces 112G0618. Price: $1.03 |
| 40 |
461DA0600 |
WASHER-SPRING,6MM This part replaces 461F0600. Price: $0.71 |
| 41 |
410AA0600 |
WASHER-PLAIN-SMALL This part replaces 410B0600. Price: $1.31 |
| 42 |
23064-006-21 |
BRACKET-HEAD LAMP Price: $10.48 |
| 43 |
28001-007 |
REFLECTOR REFLEX Price: $6.43 |
| 43 |
28012-006 |
REFLECTOR-REFLEX,FRNT Price: $23.68 |
| 44 |
461DA0500 |
WASHER-SPRING,5MM This part replaces 461F0500. Price: $0.71 |
| 45 |
311AA0500 |
NUT-HEX,5MM This part replaces 311B0500. Price: $0.47 |
| 46 |
92075-064 |
DAMPER RUBBER Price: $7.72 |
| 47 |
92075-137 |
DAMPER RUBBER Price: $5.32 |
| 51 |
44044-014 |
CIRCLIP-OIL SEAL FIT Price: $4.82 |
| 52 |
44045-030 |
GASKET FORK CYL BOLT Price: $4.99 |
