| Ref | Part Number | Description |
|---|
| 130 |
130BB0610 |
BOLT-FLANGED,6X10 Price: $2.49 |
| 130A |
130BB0614 |
BOLT-FLANGED,6X14 Price: $2.49 |
| 130B |
130BB0620 |
BOLT-FLANGED,6X20 Price: $0.46 |
| 130C |
130BB0625 |
BOLT-FLANGED,6X25 Price: $2.80 |
| 132 |
132BA0620 |
BOLT-FLANGED-SMALL,6X20 Price: $2.49 |
| 132A |
132BD0612 |
BOLT-FLANGED-SMALL,6X12 Price: $2.06 |
| 132B |
132BD0630 |
BOLT-FLANGED-SMALL,6X30 Price: $3.67 |
| 132C |
132BD0690 |
BOLT-FLANGED-SMALL,6X Price: $3.53 |
| 551 |
551A0408 |
PIN-DOWEL,4X8 Price: $0.78 |
| 11009 |
11009-1145 |
GASKET,RESERVOIR TANK CAP Price: $1.42 |
| 11012 |
11012-1084 |
CAP Price: $1.72 |
| 11055 |
11055-1953 |
BRACKET,RAD. COVER Price: $16.81 |
| 11060 |
11060-1964 |
GASKET,WATER PUMP Price: $7.58 |
| 13272 |
13272-0729 |
PLATE Price: $42.71 |
| 13272A |
13272-1202 |
PLATE Price: $8.88 |
| 13272B |
13272-1220 |
PLATE Price: $31.08 |
| 13280 |
13280-0082 |
HOLDER,BREAKER Price: $5.60 |
| 14037 |
14037-0104 |
SCREEN Price: $116.29 |
| 14092 |
14092-0083 |
COVER Price: $48.26 |
| 14092A |
14092-0086-6Z |
COVER,RADIATOR,F.BLACK Price: $31.72 |
| 14092B |
14092-0893 |
COVER Price: $48.26 |
| 14092C |
14092-1015 |
COVER Price: $37.60 |
| 16073 |
16073-0736 |
INSULATOR Price: $7.58 |
| 16073A |
16073-0737 |
INSULATOR Price: $12.31 |
| 16142 |
16142-0727 |
COVER-PUMP,WATER This part replaces 16142-0002. Price: $83.83 |
| 16160 |
16160-0189 |
BODY,THERMOSTAT,LWR Price: $79.78 |
| 16160A |
16160-0778 |
BODY,THERMOSTAT,UPP This part replaces 16160-0225. Price: $67.23 |
| 21008 |
21008-0008 |
BREAKER,RAD. FAN,12A Price: $29.57 |
| 39061 |
39061-0180 |
RADIATOR-ASSY Price: $455.41 |
| 39062 |
39062-0316 |
HOSE-COOLING,FR HEAD-THERMO Price: $12.10 |
| 39062A |
39062-0317 |
HOSE-COOLING,THERMO-R Price: $12.68 |
| 39062B |
39062-0318 |
HOSE-COOLING,RH PIPE- Price: $31.74 |
| 39062C |
39062-0319 |
HOSE-COOLING,RAD.-LH Price: $31.74 |
| 39062D |
39062-0320 |
HOSE-COOLING,RAD.-W/P Price: $10.35 |
| 39062E |
39062-0324 |
HOSE-COOLING,5.5X10.5 Price: $11.04 |
| 39062F |
39062-0608 |
HOSE-COOLING,5.5X10.5 Price: $18.31 |
| 39192 |
39192-0121 |
PIPE-WATER,RH Price: $69.27 |
| 39192A |
39192-0122 |
PIPE-WATER,LH Price: $69.27 |
| 43078 |
43078-0041 |
RESERVOIR Price: $54.40 |
| 49054 |
49054-1055 |
THERMOSTAT Price: $54.56 |
| 49063 |
49063-1055 |
SEAL-MECHANICAL Price: $20.06 |
| 49085 |
49085-0005 |
CAP-ASSY-PRESSURE Price: $45.60 |
| 59256 |
59256-1069 |
IMPELLER Price: $21.38 |
| 59502 |
59502-0564 |
FAN-ASSY Price: $345.58 |
| 92009 |
92009-1694 |
SCREW,6X16 This part replaces 92009-1621. Price: $3.92 |
| 92015 |
92015-1487 |
NUT Price: $4.80 |
| 92022 |
92022-1342 |
WASHER,6.5X16X2 Price: $3.92 |
| 92022A |
92022-1346 |
WASHER,6.5X20X1.6,BLACK Price: $0.49 |
| 92022B |
92022-304 |
WASHER,6.2X11X1 Price: $3.65 |
| 92037 |
92037-147 |
CLAMP,TUBE Price: $7.34 |
| 92037A |
92037-1589 |
CLAMP,COOLING HOSE Price: $18.57 |
| 92037B |
92037-2113 |
CLAMP Price: $1.03 |
| 92039 |
92039-0776 |
RIVET This part replaces 92039-1229. Price: $1.19 |
| 92055 |
670B2022 |
O RING,22MM This part replaces 92055-1081. Price: $4.69 |
| 92055A |
92055-1279 |
RING-O,44.7X2.4 Price: $7.34 |
| 92072 |
92072-032 |
BAND,L=218 Price: $5.00 |
| 92072A |
92072-056 |
BAND,L=186 Price: $5.00 |
| 92072B |
92072-3509 |
BAND,L=292.1 Price: $2.12 |
| 92075 |
92075-1123 |
DAMPER,RUBBER Price: $5.00 |
| 92075A |
92075-209 |
DAMPER Price: $4.69 |
| 92143 |
92143-1087 |
COLLAR Price: $4.31 |
| 92143A |
92143-1353 |
COLLAR Price: $8.58 |
| 92154 |
92154-0338 |
BOLT Price: $11.14 |
| 92170 |
92171-0261 |
CLAMP This part replaces 92170-1497. Price: $16.83 |
| 92171 |
92171-0060 |
CLAMP,COOLING HOSE Price: $4.41 |
| 92172 |
92172-0739 |
SCREW,TAPPING,6X16 Price: $0.85 |
