| Ref | Part Number | Description |
|---|
| 11061 |
11061-Y003 |
GASKET,CRANK CASE Price: $7.77 |
| 11061A |
11061-Y007 |
GASKET,CLUTCH COVER Price: $19.03 |
| 13216 |
13216-Y002 |
GEAR-COMP,KICK DRIVEN Price: $37.45 |
| 13271 |
13271-Y002 |
PLATE Price: $4.55 |
| 14032 |
14032-Y002-976 |
COVER-CLUTCH,F.BLACK This part replaces 14032-Y002-931. Price: $101.76 |
| 14080 |
14080-Y003 |
CRANKCASE,LH Price: $313.65 |
| 14080A |
14080-Y007 |
CRANKCASE,RH Price: $162.48 |
| 39115 |
39115-Y001 |
SHAFT-IDLER,KICK Price: $2.98 |
| 59051 |
59051-Y001 |
GEAR-SPUR,KICK STARTER Price: $37.45 |
| 92004 |
92004-Y002 |
STUD,8X182.5 Price: $5.90 |
| 92004A |
92004-Y004 |
STUD,8X190.5 Price: $5.90 |
| 92033 |
92033-Y012 |
RING-SNAP Price: $0.79 |
| 92043 |
92043-Y012 |
PIN,8X14 Price: $1.88 |
| 92045 |
92045-Y006 |
BEARING-BALL,6203 Price: $11.29 |
| 92045A |
92045-Y007 |
BEARING-BALL,6204 Price: $14.90 |
| 92046 |
92046-Y003 |
BEARING-NEEDLE Price: $11.86 |
| 92049 |
92049-Y004 |
SEAL-OIL,20X32X6 Price: $2.23 |
| 92049A |
92049-Y041 |
SEAL-OIL,19.8X30X5 Price: $14.95 |
| 92066 |
92066-Y003 |
PLUG,DRAIN Price: $3.57 |
| 92066A |
92066-Y005 |
PLUG Price: $17.68 |
| 92066B |
92066-Y007 |
PLUG Price: $3.12 |
| 92092 |
92092-Y002 |
BUSHING-RUBBER Price: $5.65 |
| 92139 |
92139-Y001 |
BUSHING Price: $5.90 |
| 92139A |
92139-Y002 |
BUSHING Price: $1.63 |
| 92145 |
92145-Y001 |
SPRING Price: $12.03 |
| 92145A |
92145-Y011 |
SPRING,KICK DRIVEN GEAR Price: $1.90 |
| 92152 |
92152-Y006 |
COLLAR Price: $1.74 |
| 92153 |
92153-Y031 |
BOLT,FLANGE,8X12 Price: $1.90 |
| 92153A |
92153-Y058 |
BOLT,5X10 Price: $0.79 |
| 92154 |
92154-Y068 |
BOLT,FLANGE,6X28 Price: $2.39 |
| 92154A |
92154-Y069 |
BOLT,FLANGE,6X35 Price: $2.39 |
| 92154B |
92154-Y135 |
BOLT,FLANGE,6X45 Price: $5.03 |
| 92154C |
92154-Y136 |
BOLT,FLANGE,8X45 Price: $2.60 |
| 92154D |
92154-Y141 |
BOLT,FLANGE,8X60 Price: $4.39 |
| 92200 |
92200-Y001 |
WASHER,8MM Price: $0.79 |
| 92200A |
92200-Y002 |
WASHER,10MM Price: $1.87 |
