| Ref | Part Number | Description |
|---|
| 220 |
220E0408 |
SCREW-PAN-CROS Price: $3.30 |
| 11009 |
11009-1127 |
GASKET,FORK CYLINDER BOLT Price: $5.18 |
| 11009A |
44045-002 |
GASKET,FORK DRAIN PLUG Price: $5.18 |
| 11012 |
11012-1500 |
CAP,FORK TOP Price: $13.57 |
| 11012A |
11012-1501 |
CAP,FORK TOP Price: $12.95 |
| 16126 |
16126-1150 |
VALVE Price: $46.65 |
| 44001 |
44001-1623 |
FORK-FRONT Price: $2,176.55 |
| 44005 |
44005-1251 |
PIPE-LEFT FORK OUTER Price: $429.24 |
| 44006 |
44006-1250 |
PIPE-RIGHT FORK OUTER Price: $490.36 |
| 44013 |
44013-1254 |
PIPE-FORK INNER Price: $421.21 |
| 44022 |
44022-1197 |
CYLINDER-FORK Price: $125.23 |
| 44026 |
44026-1340 |
SPRING-FRONT FORK Price: $82.87 |
| 44028 |
44028-1059 |
GUIDE-FORK SPRING Price: $8.72 |
| 44029 |
44029-1122 |
SEAT-FORK SPRING Price: $58.13 |
| 44037 |
44037-1198 |
HOLDER-FORK UNDER Price: $551.92 |
| 44039 |
44039-1248 |
HOLDER-FORK UPPER This part replaces 44039-1135. Price: $316.18 |
| 44065 |
44065-1085 |
BUSHING-FRONT FORK This part replaces 44065-1064. Price: $32.93 |
| 44065A |
44065-1081 |
BUSHING-FRONT FORK,IN Price: $21.55 |
| 51044 |
51044-1083 |
TUBE-ASSY,FORK,AIR Price: $145.94 |
| 56040 |
56040-1117 |
LABEL-WARNING,SHOCKAB Price: $5.06 |
| 92001 |
92001-1309 |
BOLT,FORK CYLINDER Price: $7.62 |
| 92002 |
92002-1158 |
BOLT,FLANGED,8X55 Price: $9.23 |
| 92002A |
120CA0845 |
BOLT-SOCKET,8X45 This part replaces 92002-1847. Price: $5.16 |
| 92002B |
92002-1848 |
BOLT,FLANGED,8X50 Price: $14.86 |
| 92015 |
92210-0004 |
NUT,FLANGED,8MM This part replaces 92015-1408. Price: $5.38 |
| 92022 |
92022-1298 |
WASHER,FORK OUTER TUBE Price: $8.58 |
| 92022A |
92022-1598 |
WASHER Price: $8.05 |
| 92026 |
92026-1277 |
SPACER,FORK SPRING Price: $7.62 |
| 92033 |
92033-1036 |
RING-SNAP Price: $6.51 |
| 92049 |
92049-1356 |
SEAL-OIL,FORK OUTER TUBE This part replaces 92049-1273. Price: $19.34 |
| 92055A |
92055-1106 |
O RING,HOSE ASSY Price: $6.54 |
| 92072 |
92072-1157 |
BAND Price: $9.03 |
| 92093 |
92093-1359 |
SEAL,FORK OUTER TUBE This part replaces 92093-1232. Price: $21.09 |
