| Ref | Part Number | Description |
|---|
| 1 |
113B1236A |
BOLT-HEX HEAD,12X36 Price: $5.54 |
| 2 |
461DA1200 |
WASHER-SPRING,12MM This part replaces 461F1200. Price: $1.03 |
| 3 |
34028-011 |
BAR-FOOTREST,L.H Price: $29.20 |
| 4 |
92022-250 |
WASHER,25X36X2.3 Price: $5.00 |
| 5 |
92043-080 |
PIN,8X31 Price: $5.52 |
| 6 |
34003-053 |
BRACKET,FOOTREST,L.H Price: $112.13 |
| 7 |
550D2516 |
PIN COTTER 2.5X16 Price: $2.79 |
| 8 |
34025-007 |
SPRING,SIDE STAND Price: $5.49 |
| 9 |
92002-1813 |
BOLT,SIDE STAND This part replaces 92003-157. Price: $9.91 |
| 10 |
34024-048 |
STAND-SIDE Price: $31.80 |
| 11 |
315AA1000 |
NUT-HEX-FINE,10MM This part replaces 315B1000. Price: $0.59 |
| 12 |
34028-009 |
STEP,RR Price: $26.11 |
| 13 |
92076-024 |
RUBBER,REAR FOOTREST Price: $24.87 |
| 14 |
92022-199 |
WASHER-PLAIN (OPT) Price: $11.60 |
| 15 |
92043-1464 |
PIN,6X28 Price: $8.10 |
| 16 |
32054-1021 |
BRACKET,STEP Price: $24.97 |
| 17 |
550AA2012 |
PIN,COTTER,2.0X12 This part replaces 550D2012. Price: $1.11 |
| 18 |
113B1056 |
BOLT,HEX HEAD,10X56 Price: $3.12 |
| 20 |
410AA1000 |
WASHER-PLAIN-SMALL,10MM This part replaces 410B1000. Price: $0.59 |
| 21 |
461DA1000 |
WASHER-SPRING,10MM This part replaces 461F1000. Price: $0.68 |
| 22 |
314AA1000 |
NUT-HEX-FINE This part replaces 314B1000. Price: $0.68 |
| 23 |
34019-015 |
SHAFT,MAIN STAND Price: $17.42 |
| 24 |
34023-016 |
SPRING,MAIN STAND Price: $16.50 |
| 26 |
550AA3030 |
PIN-COTTER,3.0X30 This part replaces 550D3030. Price: $2.51 |
| 27 |
110R0635 |
BOLT 6X35 Price: $5.96 |
| 28 |
410AA0600 |
WASHER-PLAIN-SMALL This part replaces 410B0600. Price: $1.31 |
| 29 |
92019-008 |
NUT,LOCK,6MM Price: $4.26 |
| 30 |
92043-090 |
PIN,BRAKE ROD FITTING Price: $5.68 |
| 31 |
112BA0625 |
BOLT-UPSET,6X25 This part replaces 112G0625. Price: $3.72 |
| 32 |
43001-064 |
PEDAL,BRAKE Price: $111.77 |
| 33 |
311AA0600 |
NUT-HEX,6MM This part replaces 311B0600. Price: $0.96 |
| 34 |
43005-029 |
SPRING,BRAKE PEDAL Price: $9.34 |
| 35 |
34003-054 |
BRACKET,FOOTREST,R.H Price: $36.81 |
| 36 |
92022-1561 |
WASHER,8.5X20X1.6 Price: $4.31 |
| 37 |
461DA0800 |
WASHER-SPRING,8MM This part replaces 461F0800. Price: $0.40 |
| 38 |
92019-013 |
NUT,CAP AND LOCK,8MM Price: $14.88 |
| 39 |
43011-026 |
ROD,BRAKE Price: $18.69 |
| 40 |
43012-001 |
SPRING,BRAKE ROD Price: $4.65 |
| 41 |
92043-065 |
PIN-BRAKE ROD Price: $5.57 |
| 42 |
92015-042 |
NUT,BRAKE ROD Price: $6.22 |
