| Ref | Part Number | Description |
|---|
| 4 |
220E0610 |
SCREW PAN HEAD 6X10 Price: $4.97 |
| 5 |
411AA0600 |
WASHER-PLAIN,6MM This part replaces 411B0600. Price: $2.92 |
| 6 |
461DA0600 |
WASHER-SPRING,6MM This part replaces 461F0600. Price: $0.71 |
| 7 |
312AA0600 |
NUT-HEX This part replaces 312B0600. Price: $0.73 |
| 9 |
112BA0630 |
BOLT-UPSET This part replaces 112G0630. Price: $1.38 |
| 12 |
92200-0283 |
WASHER,6.5X20X1.6 This part replaces 92022-125. Price: $1.40 |
| 13 |
461DA0600 |
WASHER-SPRING,6MM This part replaces 461F0600. Price: $0.71 |
| 17 |
35025-016 |
BRACKET REAR FENDER Price: $3.85 |
| 18 |
35025-017 |
BRACKET REAR FENDER Price: $4.73 |
| 19 |
92071-010 |
GROMMET HARNESS 10MM Price: $4.12 |
| 20 |
92071-019 |
GROMMET HARNESS 10MM Price: $3.89 |
| 21 |
220AA0614 |
SCREW-PAN-CROS,6X14 This part replaces 220B0614. Price: $1.48 |
| 22 |
411AA0600 |
WASHER-PLAIN,6MM This part replaces 411B0600. Price: $2.92 |
| 23 |
35024-002 |
CLIP WIRING HARNESS Price: $3.96 |
| 24 |
32103-015 |
RUBBER R FEND SUPPORT Price: $1.23 |
