| Ref | Part Number | Description |
|---|
| 1 |
92046-026 |
BEARING-NEEDLE Price: $23.97 |
| 12 |
13239-002 |
DRUM ASSY-GEAR CHANGE Price: $143.91 |
| 13 |
220AA0614 |
SCREW-PAN-CROS,6X14 This part replaces 220B0614. Price: $1.48 |
| 14 |
464H0600 |
WASHER LOCK 6MM Price: $0.68 |
| 15 |
13142-009 |
PLATE-CHANGE DRUM PIN Price: $4.35 |
| 16 |
92042-014 |
PIN,DOWEL,4X15.8 Price: $0.43 |
| 17 |
21007-1003 |
ROTOR,NEUTRAL INDICTR Price: $7.62 |
| 18 |
410AA0600 |
WASHER-PLAIN-SMALL This part replaces 410B0600. Price: $1.31 |
| 19 |
220AA0616 |
SCREW-PAN-CROS,6X16 This part replaces 220B0616. Price: $3.04 |
| 20 |
13146-002 |
GASKET NEUTRAL SWITCH Price: $4.35 |
| 21 |
13151-1001 |
SWITCH,NEUTRAL Price: $14.51 |
| 22 |
13140-050 |
FORK-SELECTOR,LOW Price: $55.37 |
| 23 |
92043-005 |
PIN SELECT FORK GUIDE Price: $5.40 |
| 24 |
550AA3020 |
PIN-COTTER,3.0X20 This part replaces 550D3020. Price: $1.78 |
| 25 |
13140-049 |
FORK-SELECTOR,TOP Price: $59.28 |
| 26 |
13140-030 |
FORK-SELECTOR Price: $91.86 |
| 27 |
480J1500 |
CIRCLIP-TYPE-C,15MM Price: $2.31 |
| 32 |
600A0500 |
BALL-STEEL,5/32 Price: $0.81 |
| 33 |
92024-031 |
WASHER-LOCK Price: $6.42 |
| 37 |
13128-028 |
SHAFT-OUTPUT Price: $111.00 |
| 38 |
92027-180 |
COLLAR-ENG SPROCKET Price: $40.68 |
| 39 |
92055-022 |
RING-O,17.5X1.5 Price: $6.22 |
| 41 |
92024-002 |
WASHER LOCK 12MM Price: $5.23 |
