| Ref | Part Number | Description |
|---|
| 110 |
112BA0625 |
BOLT-UPSET,6X25 This part replaces 112G0625. Price: $3.72 |
| 220 |
220AA0614 |
SCREW-PAN-CROS,6X14 This part replaces 220B0614. Price: $1.48 |
| 311 |
311BA0600 |
NUT-HEX,6MM This part replaces 311G0600. Price: $2.23 |
| 312 |
312AA0600 |
NUT-HEX This part replaces 312B0600. Price: $0.73 |
| 411 |
411AA0600 |
WASHER-PLAIN,6MM This part replaces 411B0600. Price: $2.92 |
| 12046 |
12046-1004 |
SPROCKET,STARTER MOTO Price: $59.43 |
| 12046A |
12046-1023 |
SPROCKET,STARTER Price: $67.69 |
| 13169 |
13169-1010 |
PLATE Price: $7.29 |
| 13193 |
13193-1006 |
CLUTCH ASSY,STARTING Price: $178.91 |
| 21039 |
21039-004 |
BRUSH CARBON Price: $41.68 |
| 21040 |
21040-004 |
SPRING CARBON BRUSH Price: $11.44 |
| 21163 |
21163-1238 |
STARTER, ELECTRIC This part replaces 21163-1036. Price: $502.58 |
| 26011 |
26011-1201 |
WIRE-LEAD,STARTER MOT Price: $48.53 |
| 27010 |
21164-005 |
SWITCH ASSY,MAGNETIC Price: $159.50 |
| 92001 |
92001-1046 |
SCREW,PAN HEAD,6X130 Price: $8.55 |
| 92001A |
120CA0816 |
BOLT-SOCKET,8X16 This part replaces 120P0816. Price: $4.45 |
| 92022 |
21025-008 |
WASHER,PLAIN,14MM Price: $4.83 |
| 92022A |
21025-009 |
WASHER PLAIN 14MM Price: $4.83 |
| 92022B |
21025-010 |
WASHER,THRUST,1.6T Price: $6.30 |
| 92022C |
21025-011 |
WASHER,9.1X18X0.2 Price: $6.22 |
| 92033 |
92033-037 |
CIRCLIP,13M/M Price: $9.80 |
| 92037 |
92037-1049 |
CLAMP,CABLE Price: $3.60 |
| 92043 |
92043-087 |
PIN Price: $12.76 |
| 92055 |
92055-1313 |
RING-O This part replaces 21027-005. Price: $8.66 |
| 92057 |
92057-1009 |
CHAIN,DYNAMO Price: $49.50 |
| 92071 |
21017-020 |
CAP,STARTING MOTOR Price: $8.42 |
| 92075 |
92161-1722 |
DAMPER,MAGNETIC SWITCH This part replaces 21064-002. Price: $19.64 |
| 92081 |
92081-110 |
SPRING Price: $4.76 |
| 92122 |
92122-001 |
PIN Price: $11.60 |
