| Ref | Part Number | Description |
|---|
| 130 |
130C0610 |
BOLT-FLANGED,6X10,BLACK Price: $2.86 |
| 130A |
130BA0612 |
BOLT-FLANGED,6X12 This part replaces 130H0612. Price: $1.72 |
| 220 |
220AA0514 |
SCREW-PAN-CROS,5X14 This part replaces 220D0514. Price: $4.43 |
| 671 |
671B2525 |
O RING,25MM Price: $5.00 |
| 11009 |
11009-1145 |
GASKET,RESERVOIR TANK CAP Price: $1.42 |
| 11012 |
11012-1084 |
CAP Price: $1.72 |
| 11047 |
11047-1887 |
BRACKET,THERMOSTAT BO Price: $15.89 |
| 11052 |
11052-1718 |
BRACKET,RESERVOIR Price: $9.39 |
| 14037 |
14037-1172 |
SCREEN,RADIATOR Price: $96.85 |
| 14075 |
16160-1116 |
BODY,THERMOSTAT,UPP This part replaces 14075-1068. Price: $105.56 |
| 16160 |
16160-1117 |
BODY,THERMOSTAT,LWR Price: $83.86 |
| 21176 |
21176-1054 |
SENSOR,WATER Price: $73.59 |
| 27002 |
27002-1086 |
RELAY-ASSY Price: $36.91 |
| 27010 |
27010-1443 |
SWITCH Price: $135.39 |
| 39060 |
39060-1181 |
RADIATOR Price: $1,031.09 |
| 39062 |
39062-1377 |
HOSE-COOLING Price: $37.86 |
| 39062A |
39062-1531 |
HOSE-COOLING,THERMO-R Price: $37.86 |
| 39062B |
39062-1542 |
HOSE-COOLING,HEAD-THE Price: $54.40 |
| 39062C |
39062-1894 |
HOSE-COOLING,OVERFLOW Price: $41.55 |
| 39062D |
39062-1895 |
HOSE-COOLING,THERMOST Price: $26.59 |
| 39062E |
39062-1897 |
HOSE-COOLING,PUMP-CYL Price: $32.68 |
| 39192 |
39192-1011 |
PIPE-WATER,PUMP-CYLINDER Price: $74.82 |
| 39192A |
39192-1145 |
PIPE-WATER,INLET Price: $117.90 |
| 39192B |
39192-1146 |
PIPE-WATER,INLET Price: $117.90 |
| 39192C |
39192-1147 |
PIPE-WATER,OUTLET Price: $129.89 |
| 43056 |
43085-001 |
BLEEDER SET This part replaces 43056-003. Price: $24.57 |
| 43078 |
43078-1183 |
RESERVOIR Price: $81.81 |
| 49016 |
49016-1166 |
COVER-SEAL Price: $44.47 |
| 49016A |
49016-1215 |
COVER-SEAL,HEAD COVER Price: $36.54 |
| 49044 |
49044-1080 |
PUMP-WATER Price: $295.67 |
| 49054 |
49054-1051 |
THERMOSTAT Price: $41.50 |
| 49085 |
49085-1067 |
CAP-ASSY-PRESSURE Price: $53.94 |
| 53044 |
53044-1331 |
TRIM,L=403 Price: $30.83 |
| 53044A |
53044-1332 |
TRIM,L=70 Price: $8.54 |
| 59502 |
59502-1145 |
FAN-ASSY,LH Price: $780.32 |
| 59502A |
59502-1146 |
FAN-ASSY,RH Price: $780.32 |
| 92002 |
130BA0616 |
BOLT-FLANGED,6X16 This part replaces 92002-1099. Price: $1.20 |
| 92002A |
92002-1392 |
BOLT,6X22 Price: $4.73 |
| 92002B |
92002-1566 |
BOLT,6X40 Price: $5.30 |
| 92002C |
132BB0612 |
BOLT-FLANGED-SMALL,6X12 This part replaces 92002-1569. Price: $2.06 |
| 92002D |
92154-1893 |
BOLT,FLANGED-SMALL,6X16 This part replaces 92002-1571. Price: $4.69 |
| 92009 |
92172-0003 |
SCREW,TAPPING,6X12 This part replaces 92009-1261. Price: $2.80 |
| 92015 |
92015-1487 |
NUT Price: $4.80 |
| 92015A |
92015-1758 |
NUT,6MM Price: $6.88 |
| 92022 |
92022-1976 |
WASHER,6MM Price: $6.27 |
| 92022A |
92022-304 |
WASHER,6.2X11X1 Price: $3.65 |
| 92027 |
92027-1134 |
COLLAR,L=14 Price: $10.28 |
| 92037 |
92037-147 |
CLAMP,TUBE Price: $7.34 |
| 92055 |
92055-112 |
RING-O,53.5X2.6 Price: $6.63 |
| 92055A |
92055-1282 |
RING-O Price: $5.24 |
| 92055B |
92055-1423 |
RING-O,WATER PUMP INSIDE Price: $9.37 |
| 92055C |
92055-1424 |
RING-O,33.2X2.4 Price: $6.27 |
| 92075 |
92075-1634 |
DAMPER Price: $4.69 |
| 92143 |
92143-1962 |
COLLAR Price: $6.22 |
| 92150 |
92150-1007 |
BOLT Price: $4.78 |
| 92150A |
92150-1186 |
BOLT,6X12 Price: $3.37 |
| 92150B |
92150-1826 |
BOLT,FLANGED,6X12 Price: $3.65 |
| 92151 |
92151-1997 |
BOLT,6X12 Price: $1.54 |
| 92153 |
92153-1170 |
BOLT,M6 Price: $1.74 |
| 92160 |
92160-1007 |
DAMPER Price: $5.52 |
| 92161 |
92161-1277 |
DAMPER,HEAT GUARD Price: $3.86 |
| 92170 |
92171-0652 |
CLAMP,L=60 This part replaces 92170-1937. Price: $2.61 |
| 92171 |
92171-0179 |
CLAMP Price: $8.20 |
