| Ref | Part Number | Description |
|---|
| 3 |
93311-928U5-00 |
BEARING Price: $144.99 |
| 4 |
93390-000U2-00 |
BEARING Price: $187.99 |
| 5 |
93341-465U4-00 |
BEARING Price: $66.99 |
| 7 |
90340-08002-00 |
PLUG, STRAIGHT SCREW Price: $12.75 |
| 8 |
688-45341-10-00 |
PLUG, DRAIN Price: $12.70 |
| 9 |
90430-08003-00 |
GASKET Price: $1.55 |
| 10 |
6G5-45536-01-00 |
SLEEVE, DRIVE SHAFT Price: $18.75 |
| 11 |
663-45376-00-00 |
GUIDE, SEAL DAMPER Price: $14.90 |
| 12 |
688-45375-00-00 |
DAMPER, SEAL Price: $13.75 |
| 13 |
63P-45378-00-00 |
NIPPLE, HOSE Price: $6.75 |
| 14 |
93210-07540-00 |
O-RING This part replaces 93210-07003-00. Price: $7.49 |
| 15 |
6E5-45321-00-00 |
PLATE Price: $63.80 |
| 16 |
93210-58677-00 |
O-RING This part replaces 93210-58144-00. Price: $8.49 |
| 17 |
93106-09014-00 |
OIL SEAL Price: $8.40 |
| 18 |
90119-06286-00 |
BOLT, WITH WASHER Price: $6.25 |
| 19 |
64P-44150-01-00 |
SHIFT CAM ASSY Price: $241.30 |
| 20 |
99001-08600-00 |
CIRCLIP Price: $9.49 |
| 21 |
61A-45538-00-00 |
SPACER 1 Price: $7.60 |
| 22 |
90201-22M01-00 |
WASHER, PLATE Price: $4.15 |
| 23 |
90206-22M19-00 |
WASHER, WAVE Price: $6.15 |
| 24 |
61A-45527-00-00 |
COLLAR, DRIVE SHAFT Price: $12.75 |
| 25 |
61A-44311-01-00 |
HOUSING, WATER PUMP Price: $33.70 |
| 26 |
61A-44322-02-00 |
INSERT, CARTRIDGE Price: $50.50 |
| 27 |
93210-86M38-00 |
O-RING Price: $13.85 |
| 28 |
93210-37M67-00 |
O-RING This part replaces 93210-37160-00. Price: $3.80 |
| 30 |
6E5-44312-00-00 |
COVER, WATER PUMP HOUSING Price: $3.50 |
| 31 |
6E5-44352-01-00 |
IMPELLER Price: $33.65 |
| 32 |
90280-04M05-00 |
WOODRUFF KEY, DRIVESHAFT Price: $14.35 |
| 33 |
6G5-44323-01-00 |
OUTER PLATE, CARTRIDGE Price: $18.70 |
| 34 |
6E5-44315-A0-00 |
GASKET, WATER PUMP Price: $6.15 |
| 35 |
93606-12019-00 |
PIN, DOWEL Price: $4.60 |
| 36 |
90119-08191-00 |
BOLT, WITH WASHER Price: $4.80 |
| 37 |
6E5-45331-00-9S |
HOUSING, BEARING Price: $133.55 |
| 38 |
93101-28M16-00 |
OIL SEAL Price: $11.40 |
| 39 |
93315-430V5-00 |
BEARING This part replaces 93317-330U2-00. Price: $26.99 |
| 41 |
93341-930V2-00 |
BEARING Price: $174.99 |
| 42 |
93210-54534-00 |
O-RING This part replaces 93210-55M14-00. Price: $5.95 |
| 43 |
6E5-45344-00-00 |
COVER, OIL SEAL Price: $19.35 |
| 44 |
97E95-08525-00 |
BOLT, HEXAGON W/W Price: $1.50 |
| 46 |
6DA-45551-00-00 |
PINION (14T) Price: $268.45 |
| 47 |
90170-16M01-00 |
NUT Price: $7.49 |
| 48 |
6DB-45560-00-00 |
GEAR 1 (26T) Price: $383.55 |
| 49 |
90201-26015-00 |
WASHER, PLATE Price: $8.25 |
| 50 |
6K1-45611-11-00 |
SHAFT, PROPELLER Price: $221.35 |
| 51 |
6E5-45634-02-00 |
SLIDE, SHIFT Price: $115.30 |
| 52 |
90501-16M37-00 |
SPRING, COMPRESSION Price: $6.75 |
| 53 |
93507-32031-00 |
BALL 7-32 This part replaces 93507-32009-00. Price: $5.49 |
| 54 |
93511-32027-00 |
BALL This part replaces 93511-32017-00. Price: $9.49 |
| 55 |
93503-16003-00 |
BALL Price: $2.90 |
| 56 |
90250-08M07-00 |
PIN, STRAIGHT Price: $9.10 |
| 57 |
6DA-45631-00-00 |
CLUTCH, DOG This part replaces 6DA-45631-01-00. Price: $175.75 |
| 58 |
6E5-45633-01-00 |
RING, CROSS PIN Price: $16.60 |
| 59 |
6K1-45332-01-CA |
HOUSING, BEARING Price: $174.65 |
| 60 |
93332-00048-00 |
BEARING Price: $133.99 |
| 61 |
6DB-45570-01-00 |
GEAR 2 (26T) Price: $485.15 |
| 62 |
6K1-45576-00-00 |
WASHER, THRUST 2 Price: $84.50 |
| 63 |
93341-440U5-00 |
BEARING Price: $47.99 |
| 65 |
93315-43061-00 |
BEARING Price: $41.99 |
| 66 |
93101-30M17-00 |
OIL SEAL Price: $14.15 |
| 67 |
93210-97M55-00 |
O-RING Price: $14.90 |
| 69 |
90282-04M00-00 |
KEY, STRAIGHT Price: $8.60 |
| 70 |
6G5-45383-01-00 |
WASHER, CLAW Price: $19.90 |
