| Ref | Part Number | Description |
|---|
| 1 |
3856270 |
INTAKE MANIFOLD |
| 2 |
3850861 |
COVER & FUEL FILTER ASSY |
| 3 |
5012363 |
Filter Ay This part replaces 0502906. |
| 4 |
3857662 |
GASKET SET, Intake manifold |
| 5 |
3855935 |
BOLT, Manifold to head |
| 6 |
0312780 |
GASKET, Dist. to manifold This part replaces 3852109. |
| 7 |
3852108 |
CLAMP, Distributor |
| 8 |
3853266 |
BOLT, Distributor |
| 9 |
0909988 |
BUSHING, Tilt & trim cable This part replaces 3852481. |
| 10 |
3857986 |
FUEL PUMP ASSY. |
| 11 |
3854163 |
CIRCUIT BREAKER, 20A Fuel pump |
| 12 |
3853545 |
FITTING, Fuel pump |
| 13 |
3850820 |
O-RING |
| 14 |
3856129 |
BOLT, Intake manifold, short |
| 15 |
3853493 |
FITTING, Filter outlet to pump |
| 18 |
3853557 |
SCREW, Brace to alterntr bracket |
| 19 |
3860811 |
Bracket This part replaces 3857411. |
| 20 |
3853310 |
BRACKET, Fuel filter |
| 23 |
3857031 |
FUEL LINE, Fuel pump to carburetor |
| 25 |
3853620 |
SCREW, Circuit breaker |
| 26 |
3853169 |
SEALER, Manifold ends |
| 27 |
3852029 |
SENDER, Water temperature |
| 28 |
3853326 |
SCREW, Bracket to engine |
| 29 |
3852019 |
TRUNNION, S.A.E. Cable |
| 31 |
3856438 |
BRACKET, Fuel filter & pump |
| 32 |
3853311 |
BRACKET, Lift |
| 33 |
3850266 |
ANCHOR BLOCK |
| 34 |
0303459 |
ECREW,Exhaust cover,1-1/2"long This part replaces 3852048. |
| 35 |
3852013 |
ELBOW, Filter inlet |
