| Ref | Part Number | Description |
|---|
| 1 |
HOSE, |
Manifold cover plate, 5/8" i.d., 9" lon |
| 2 |
HOSE, |
Water pump to exchanger, 1-3/4" i.d., 1 |
| 3 |
HOSE, |
Thermostat housing to expansion tank, 1 |
| 4 |
042-037 |
END CAP, Anode housing |
| 5 |
047-038 |
COVER, Thermostat housing |
| 6 |
079-032 |
GASKET, Thermostat housing |
| 7 |
079-033 |
GASKET, Thermostat housing cover |
| 8 |
072-018 |
THERMOSTAT, 160 deg |
| 9 |
HEAT |
EXCHANGER ASSY., Omc 313-4 |
| 10 |
SCREW, |
Upper mount 3/8" x 1-1/2" |
| 11 |
SCREW, |
Lower mount, 3/8" x 2-1/4" |
| 12 |
LOCKWASHER, |
Screw, lower |
| 13 |
NUT, |
Screw, lower, 3/8" |
| 14 |
CLAMP, |
Hose #10 |
| 15 |
CLAMP, |
Hose, #24 |
| 16 |
LEAD, |
Purple, 12" with knife disconnects on e |
| 17 |
SLEEVES, |
Neoprene |
| 18 |
CLAMP, |
Large |
| 19 |
CLAMP, |
Small |
