| Ref | Part Number | Description |
|---|
| 2a |
715900118 |
Rubber Boot |
| 2b |
509000045 |
Oetiker Gear Clamp 36.1MM |
| 6 |
703500678 |
Front Bushing Shaft Kit |
| 7 |
705400036 |
Wear Ring |
| 9 |
705401481 |
Oil Seal |
| 10 |
705401603 |
Nut This part replaces 705400661. |
| 11 |
705500260 |
Ball Bearing |
| 12 |
705501588 |
Engrenage 10 Dents - Appelez votre concessionnaire BRP local |
| 13 |
705500261 |
Needle Bearing |
| 14 |
705401606 |
Ball Bearing This part replaces 705500259. |
| 15 |
293350044 |
Ball Bearing |
| 16 |
703500871 |
Ens Differentiel*Differential Kit This part replaces 705400645. |
| 19 |
705401601 |
Screw This part replaces 705500892. |
| 20 |
705400762 |
FRONT COVER - Call your local BRP dealership |
| 21 |
705500265 |
Seal |
| 22 |
705400761 |
FRONT COVER - Call your local BRP dealership |
| 23 |
705500893 |
VENT VALVE - Call your local BRP dealership |
| 24 |
705500894 |
Drain Plug |
| 27 |
705500267 |
O-Ring |
| 28 |
705401618 |
Gasket This part replaces 705500255. |
| 29 |
705500075 |
Pinion Gear Shim .022" |
| 29 |
705501162 |
Pinion Gear Shim |
| 29 |
705502061 |
Pinion Gear Shim 1.67 mm This part replaces 703500049. |
| 30 |
705401604 |
Shim This part replaces 703500288. |
| 31 |
705401604 |
Shim This part replaces 703500050. |
| 32 |
705500504 |
Fill Level Plug |
| 33 |
705500506 |
Copper Washer |
| 35 |
Not |
Available As Spare Part - CV Joint |
| 36 |
Not |
Available As Spare Part - Wheel Boot Kit |
| 36a |
Not |
Available As Spare Part - Oetiker Clamp 23mm |
| 36b |
Not |
Available As Spare Part - Oetiker Clamp 70mm |
| 37 |
Not |
Available As Spare Part - Differential Boot Kit |
| 37a |
Not |
Available As Spare Part - Oetiker Clamp 23mm |
| 37b |
Not |
Available As Spare Part - Oetiker Clamp 67mm |
| 39 |
Not |
Available As Spare Part - Circlip |
| 40 |
705400816 |
LH Knuckle |
| 41 |
705400818 |
RH Knuckle |
| 43 |
Not |
Available As Spare Part - CV Joint |
| 44 |
Not |
Available As Spare Part - Wheel Boot Kit |
| 44a |
Not |
Available As Spare Part - Oetiker Clamp 23mm |
| 44b |
Not |
Available As Spare Part - Oetiker Clamp 70mm |
| 45 |
Not |
Available As Spare Part - Differential Boot Kit |
| 45a |
Not |
Available As Spare Part - Oetiker Clamp 23mm |
| 45b |
Not |
Available As Spare Part - Oetiker Clamp 67mm |
| 47 |
Not |
Available As Spare Part - Circlip |
| 48 |
293350150 |
Ball Bearing This part replaces 293350040. |
| 49 |
293650138 |
Oetiker Gear Clamp 44.0MM |
| 50 |
293370019 |
Circlip |
| 51 |
230602546 |
Hex. Flange Screw M10 X 125 |
| 52 |
233201436 |
Hex. Flange Elastic Nut M10 This part replaces 233201416. |
| 53 |
705501121 |
Wear Sleeve |
| 55 |
250300055 |
Wheel Stud M10 X 1.25 This part replaces 250300045. |
| 56 |
250200171 |
Conical Spring Washer M18 This part replaces 250200049. |
| 57 |
232291413 |
Hex. Flange Castellated Nut M18 This part replaces 250100047. |
| 58 |
250400036 |
Cotter Pin |
| 59 |
219704410 |
Polyurethane Hose 10000Mm Long |
| 64a |
705400193 |
Rim Valve With Cap |
| 64c |
293000110 |
Valve Cap |
| 66 |
705400780 |
Wear Sleeve |
| 67 |
250200102 |
Flat Washer M12 |
| 68 |
250000378 |
HEX FLANGED SCREW M12 X 16, SCOTCH GRIP - Call your local BRP dealership |
| 71 |
705400169 |
HOUSING - Call your local BRP dealership |
| 72a |
293370042 |
Circlip This part replaces 415129176. |
| 73 |
705400274 |
Fork |
| 74 |
293300117 |
O-Ring |
| 75 |
250000137 |
Hex. Flange Screw M8 X 20, Scotch Grip |
| 76 |
705400917 |
UNION SHAFT - Call your local BRP dealership |
| 77 |
206580890 |
Pressure Screw M8 X 8 |
| 78 |
250400025 |
Dowell Pin |
| 79 |
705400249 |
Ball Bearing |
| 80 |
705402139 |
Slider This part replaces 705400956. |
| 81 |
293370029 |
Circlip |
| 82 |
293370030 |
Circlip |
| 83 |
710000324 |
SWITCH - Call your local BRP dealership |
| 84 |
705400389 |
Coupling Sleeve |
| 85 |
293250138 |
Oil Seal |
| 86 |
705401553 |
Shifter Lever Plate This part replaces 705400387. |
| 87 |
705601628 |
Copper Washer This part replaces 705600310. |
| 89 |
250000136 |
Socket Head Screw M8 X 20, Scotch Grip |
