| Ref | Part Number | Description |
|---|
| 1 |
515175664 |
Heating Grip |
| 2 |
M39023 |
Housing |
| 4 |
605642628 |
CONNECTOR - Call your local BRP dealership This part replaces M42603. |
| 5 |
M42621 |
Housing |
| 6 |
M39015 |
Tubing 12 mm |
| 7 |
515175807 |
FEMALE TERMINAL HOUSING 8 CIRCUITS BLACK - Call your local BRP dealership |
| 8 |
515175808 |
FEMALE TERMINAL - Call your local BRP dealership |
| 9 |
515175809 |
FEMELLE LOCK, 8 CIRCUITS - Call your local BRP dealership |
| 10 |
515175810 |
FEMALE TERMINAL HOUSING, 8 CIRCUITS - Call your local BRP dealership |
| 11 |
Not |
Available As Spare Part - Male terminal housing |
| 12 |
515175941 |
Female Terminal |
| 13 |
414115200 |
Tie-Rap 180 mm |
| 14 |
512059624 |
Handle Ass’Y |
| 15 |
414227300 |
Clip |
| 16 |
515176015 |
LH SWITCH HOUSING - Call your local BRP dealership |
| 17 |
515175926 |
Switch Housing Plate |
| 18 |
M40903 |
Screw 3.5X25 |
| 19 |
507032366 |
Microswitch |
| 20 |
605642628 |
CONNECTOR - Call your local BRP dealership This part replaces M42603. |
