| Ref | Part Number | Description |
|---|
| 2 |
204073047 |
DASHBOARD MAT - Call your local BRP dealership |
| 3 |
204550028 |
SLIT CONDUIT, METER - Call your local BRP dealership |
| 4 |
207163060 |
Hex. Screw M6 X 30 |
| 5 |
293800060 |
Loctite 243, 10 ml |
| 6 |
234062600 |
Flat Washer M6, Stainless |
| 7 |
207164560 |
Hex. Screw M6 X 45 |
| 8 |
232561600 |
Hex. Elastic Stop Nut M6 |
| 9 |
204073048 |
MAT - Call your local BRP dealership |
| 10 |
204071878 |
TRIM, WHITE - Call your local BRP dealership |
| 14 |
204072759 |
Trim, White, 7/16”, Meter |
| 22 |
205441660 |
Socket Head Screw M4 X 16 |
| 23 |
293800060 |
Loctite 243, 10 ml |
| 24 |
204072980 |
Console Carpet, Starboard |
| 25 |
204073523 |
GLOVE BOXE UPPER COVER - Call your local BRP dealership This part replaces 204073402. |
| 26 |
204070940 |
BUMPER - Call your local BRP dealership |
| 28 |
204073197 |
HINGE, BLACK - Call your local BRP dealership |
| 29 |
204130226 |
SPACER - Call your local BRP dealership |
| 30 |
293150057 |
Rivet 1/8” |
| 31 |
293150285 |
Pop RIvet 1/8 X ,375 This part replaces 293150006. |
| 32 |
204073220 |
GLOVEBOX STAY - Call your local BRP dealership |
| 33 |
293150032 |
RIVET_POP 1/8 X ,487 - Call your local BRP dealership |
| 34 |
204072907 |
MAGNETIC CATCH - Call your local BRP dealership |
| 35 |
293150036 |
RIVET_POP 1/8 X ,750 - Call your local BRP dealership |
| 36 |
204072908 |
LATCH BRACKET - Call your local BRP dealership |
| 37 |
204073168 |
LATCH SPACER - Call your local BRP dealership |
| 38 |
232541600 |
Elastic Stop Nut M4 |
| 39 |
234041600 |
Flat Washer 4 mm, Stainless |
| 40 |
204073309 |
GLOVEBOX STAY BRACKET - Call your local BRP dealership |
| 41 |
293150285 |
Pop RIvet 1/8 X ,375 This part replaces 293150006. |
