| Ref | Part Number | Description |
|---|
| ACS |
515175282 |
Female Terminal |
| ACS |
515176550 |
Female Terminal Housing |
| BLS |
409209500 |
Female Housing, 2 Circuits |
| BLS |
515176621 |
Wire Seal |
| BLS |
710001340 |
Female Terminal |
| CF |
278000217 |
Female Housing, 2 Circuits |
| CF |
409004300 |
Male Terminal |
| CF |
409210100 |
Clip Bracket Connector (edge) |
| CF |
710000504 |
Wire Seal |
| CIC1 |
710001226 |
Housing |
| CIC1 |
710001228 |
Terminal |
| CIC1 |
710001229 |
Terminal |
| CIC1 |
710001332 |
Seal Wire |
| CIC2 |
710001225 |
Cap |
| CIC2 |
710001228 |
Terminal |
| CIC2 |
710001229 |
Terminal |
| CIC2 |
710001332 |
Seal Wire |
| CIC2 |
710001951 |
Housing |
| CIC3 |
710001225 |
Cap |
| CIC3 |
710001229 |
Terminal |
| CIC3 |
710001233 |
Seal |
| CIC3 |
710001928 |
Housing |
| D2 |
409012700 |
Diode |
| D2 |
Not |
Available As Spare Part - Shrink Tubing |
| DC1 |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| DC1 |
409010100 |
Female Terminal |
| DC1 |
409010400 |
Female Terminal Housing, 1 Circuit |
| DC2 |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| DC2 |
293750002 |
Tie Wrap 142 mm |
| DC2 |
409010100 |
Female Terminal |
| DC2 |
409010400 |
Female Terminal Housing, 1 Circuit |
| DC2 |
710000670 |
CAP - Call your local BRP dealership |
| DIC1 |
710001225 |
Cap |
| DIC1 |
710001226 |
Housing |
| DIC1 |
710001228 |
Terminal |
| DIC1 |
710001229 |
Terminal |
| DIC1 |
710001332 |
Seal Wire |
| DIC2 |
278002186 |
Wire Seal |
| DIC2 |
278002187 |
Female Terminal |
| DIC2 |
710001873 |
Terminal This part replaces 710001765. |
| DIC2 |
710001874 |
CONNECTOR_FEMALE 16 CAVITIES - Call your local BRP dealership |
| DIC2 |
710002075 |
Plug |
| DIC3 |
710001228 |
Terminal |
| DIC3 |
710001229 |
Terminal |
| DIC3 |
710001232 |
Housing |
| DIC3 |
710001332 |
Seal Wire |
| DLC1 |
278001665 |
Female Terminal |
| DLC1 |
515175673 |
Male Housing, 6 Circuits |
| DLC1 |
515175678 |
Male Wedge, 6 Circuits |
| DLC2 |
278001665 |
Female Terminal |
| DLC2 |
293000052 |
Sealing Cap |
| DLC2 |
414115200 |
Tie-Rap 180 mm |
| DLC2 |
515175673 |
Male Housing, 6 Circuits |
| DLC2 |
515175678 |
Male Wedge, 6 Circuits |
| DLC3 |
293000052 |
Sealing Cap |
| DLC3 |
515175668 |
Male Terminal Housing, 6 Circuits |
| DPS1 |
710001114 |
Cap |
| DPS1 |
710001161 |
Housing |
| DPS1 |
710001162 |
Lock |
| DPS1 |
710001163 |
Wire Seal |
| DPS1 |
710001164 |
Female Terminal |
| DPS1 |
710001225 |
Cap |
| DPS2 |
710001160 |
Female Terminal |
| DPS2 |
710001315 |
HOUSING - Call your local BRP dealership |
| DPS2 |
710001935 |
SEAL - Call your local BRP dealership |
| ECMB |
293750002 |
Tie Wrap 142 mm |
| ECMB |
710001588 |
Female Terminal Housing, 48 Circuits |
| ECMB |
710001589 |
Female Terminal |
| ECMB |
710001590 |
Female Terminal |
| ECMB |
710001591 |
Cover, 48 positions |
| ECMB |
710001592 |
Plug |
| ECMB |
710001727 |
Female Terminal |
| EOP |
409010100 |
Female Terminal |
| EOP |
409010400 |
Female Terminal Housing, 1 Circuit |
| FB |
278000999 |
Wire Seal |
| FB |
278002172 |
Foam |
| FB |
415128501 |
Seal |
| FB |
415129856 |
Fuse Box Base Ass´y This part replaces 710000660. |
| FB |
515176774 |
Relay, 30 AMP |
| FB |
710000742 |
Little Fuse, 5 Amperes |
| FB |
710000744 |
Little Fuse, 10 Amperes |
| FB |
710000745 |
Little Fuse, 15 Ampere |
| FB |
710000746 |
Little Fuse, 20 Amperes |
| FB |
710000836 |
Female Terminal |
| FB |
710000837 |
Female Terminal |
| FB |
710000840 |
Cap |
| FB |
710001026 |
Fuse Cover |
| FB |
710001553 |
FUSE AND RELAY DECAL - Call your local BRP dealership |
| FB |
710002185 |
LITTLE FUSE, 25 AMPERES - Call your local BRP dealership |
| FB |
715900824 |
Relay This part replaces 710001778. |
| FCS |
710001235 |
Terminal |
| FCS |
710001873 |
Terminal |
| FLH |
515175231 |
Female Terminal |
| FLH |
515175495 |
Female Housing, 3 Circuits |
| FP |
278001482 |
Seal |
| FP |
710001132 |
Housing |
| FP |
710001133 |
Lock |
| FP |
710001134 |
Female Terminal |
| FPL1 |
409209400 |
Male Terminal Housing, 2 Circuits |
| FPL1 |
414115200 |
Tie-Rap 180 mm |
| FPL1 |
515176164 |
Male Terminal |
| FPL1 |
515176621 |
Wire Seal |
| FPL1 |
710002586 |
Grommet |
| FPL2 |
409209400 |
Male Terminal Housing, 2 Circuits |
| FPL2 |
414115200 |
Tie-Rap 180 mm |
| FPL2 |
515176164 |
Male Terminal |
| FPL2 |
515176621 |
Wire Seal |
| FPL2 |
710002586 |
Grommet |
| FRH |
515175231 |
Female Terminal |
| FRH |
515175495 |
Female Housing, 3 Circuits |
| GND1 |
278001392 |
Open Barrel Terminal |
| GND1 |
Not |
Available As Spare Part - Shrink Tubing |
| GND2 |
710000913 |
Terminal |
| GND2 |
Not |
Available As Spare Part - Adhesive Tape |
| GSC |
278001665 |
Female Terminal |
| GSC |
278001744 |
SECONDARY LOCK, 8 CIRCUITS - Call your local BRP dealership |
| GSC |
710001936 |
CONNECTOR - Call your local BRP dealership |
| HA |
278001665 |
Female Terminal |
| HA |
515175670 |
Female Terminal Housing, 2 Circuits |
| HA |
515175675 |
Female Lock, 2 Circuits |
| HBS |
409013700 |
Plug |
| HBS |
409209600 |
Female Housing, 3 Circuits |
| HBS |
515176621 |
Wire Seal |
| HBS |
710001340 |
Female Terminal |
| HIC |
278000632 |
Female Terminal |
| HIC |
515175672 |
CONNECTOR_MALE 4 CAVITIES - Call your local BRP dealership |
| HIC |
515175677 |
MALE WEDGE, 4 CIRCUITS - Call your local BRP dealership |
| HN3 |
515175231 |
Female Terminal |
| HN3 |
515175658 |
Female Housing, 2 Circuits |
| HO2S1 |
278001482 |
Seal |
| HO2S1 |
710002466 |
Housing |
| HO2S1 |
710002469 |
Lock |
| HO2S1 |
710002597 |
Gold Terminal |
| HO2S2 |
278001482 |
Seal |
| HO2S2 |
710002466 |
Housing |
| HO2S2 |
710002469 |
Lock |
| HO2S2 |
710002597 |
Gold Terminal |
| IK |
414115200 |
Tie-Rap 180 mm |
| IK |
710000487 |
Coding Tape |
| IK |
710001128 |
HOUSING - Call your local BRP dealership |
| IK |
710001130 |
FEMALE TERMINAL - Call your local BRP dealership |
| IK |
710001338 |
CAP - Call your local BRP dealership This part replaces 710001129. |
| JMP1 |
710001229 |
Terminal |
| JMP1 |
710001233 |
Seal |
| JMP1 |
710002592 |
Housing |
| JMP2 |
409210100 |
Clip Bracket Connector (edge) |
| JMP2 |
710001224 |
Terminal |
| JMP2 |
710001225 |
Cap |
| JMP2 |
710001233 |
Seal |
| JMP2 |
710002593 |
Housing |
| LBHL |
278001013 |
Wire Seal |
| LBHL |
278001014 |
Female Terminal |
| LBHL |
409209600 |
Female Housing, 3 Circuits |
| LED |
409209500 |
Female Housing, 2 Circuits |
| LED |
515176621 |
Wire Seal |
| LED |
710001340 |
Female Terminal |
| LPS |
409013700 |
Plug |
| LPS |
409209600 |
Female Housing, 3 Circuits |
| LPS |
515176621 |
Wire Seal |
| LPS |
710001340 |
Female Terminal |
| MFB1 |
710001051 |
MALE TERMINAL - Call your local BRP dealership |
| MFB1 |
710001052 |
FUSE HOLDER - Call your local BRP dealership |
| MFB2 |
710001050 |
MALE TERMINAL - Call your local BRP dealership |
| MFB2 |
710001053 |
FUSE HOLDER - Call your local BRP dealership |
| MFB34 |
710001051 |
MALE TERMINAL - Call your local BRP dealership |
| MFB34 |
710001057 |
FUSE HOLDER - Call your local BRP dealership |
| MFB56 |
710001051 |
MALE TERMINAL - Call your local BRP dealership |
| MFB56 |
710001054 |
FUSE HOLDER - Call your local BRP dealership |
| MFB78 |
710001050 |
MALE TERMINAL - Call your local BRP dealership |
| MFB78 |
710001055 |
FUSE HOLDER - Call your local BRP dealership |
| MSL2 |
278001013 |
Wire Seal |
| MSL2 |
278001014 |
Female Terminal |
| MSL2 |
515176621 |
Wire Seal |
| MSL2 |
710000816 |
CONNECTOR - Call your local BRP dealership |
| MSL2 |
710001340 |
Female Terminal |
| MSL3 |
409013700 |
Plug |
| MSL3 |
515176164 |
Male Terminal |
| MSL3 |
515176621 |
Wire Seal |
| MSL3 |
710000568 |
Housing |
| MSR2 |
515176164 |
Male Terminal |
| MSR2 |
515176621 |
Wire Seal |
| MSR2 |
710000815 |
Housing, 6 Circuits |
| OLS1 |
515177043 |
Housing 2 Circuits |
| OLS1 |
710001163 |
Wire Seal |
| OLS1 |
710001164 |
Female Terminal |
| OLS2 |
515177043 |
Housing 2 Circuits |
| OLS2 |
710001163 |
Wire Seal |
| OLS2 |
710001164 |
Female Terminal |
| PBM1 |
278001007 |
Insulated Sheath |
| PBM1 |
710000421 |
Female Terminal |
| PBM2 |
278001008 |
Insulated Sheath |
| PBM2 |
278002261 |
Female Terminal |
| PIC1 |
710001225 |
Cap |
| PIC1 |
710001228 |
Terminal |
| PIC1 |
710001229 |
Terminal |
| PIC1 |
710001332 |
Seal Wire |
| PIC1 |
710001943 |
Housing |
| PIC2 |
710001225 |
Cap |
| PIC2 |
710001229 |
Terminal |
| PIC2 |
710001233 |
Seal |
| PIC2 |
710001928 |
Housing |
| PRS |
409207600 |
Male Lock, 3 Circuits |
| PRS |
515175666 |
Male Housing |
| PRS |
710001348 |
Male Terminal |
| RBHL |
278001013 |
Wire Seal |
| RBHL |
278001014 |
Female Terminal |
| RBHL |
409209600 |
Female Housing, 3 Circuits |
| SAS |
710001117 |
FEMALE TERMINAL - Call your local BRP dealership |
| SAS |
710001118 |
Wire Seal |
| SAS |
710003730 |
Housing This part replaces 710001120. |
| SPS |
414115200 |
Tie-Rap 180 mm |
| SPS |
710001117 |
FEMALE TERMINAL - Call your local BRP dealership |
| SPS |
710001118 |
Wire Seal |
| SPS |
710001938 |
Plug |
| SPS |
710002586 |
Grommet |
| SPS |
710003731 |
Housing This part replaces 710001872. |
| SRS |
515175231 |
Female Terminal |
| SRS |
515175658 |
Female Housing, 2 Circuits |
| STS1 |
710002398 |
Female Terminal |
| STS1 |
710002399 |
Female Terminal |
| STS2 |
710002398 |
Female Terminal |
| STS2 |
710002399 |
Female Terminal |
| TAS |
710001229 |
Terminal |
| TAS |
710001232 |
Housing |
| TAS |
710001233 |
Seal |
| TCM |
293750002 |
Tie Wrap 142 mm |
| TCM |
515175806 |
Female Terminal |
| TCM |
515175812 |
Plug |
| TCM |
515176221 |
Female Housing |
| TCM |
515176222 |
Wire Seal |
| TCM |
515176223 |
Female Terminal Housing, 36 Circuits |
| TCM |
515176224 |
Terminal Support |
| TCM |
710001131 |
Female Terminal |
| VCM |
293750002 |
Tie Wrap 142 mm |
| VCM |
710001118 |
Wire Seal |
| VCM |
710001867 |
TERMINAL - Call your local BRP dealership |
| VCM |
710001869 |
Terminal |
| VCM |
710001870 |
MOLEX HOUSING, 38 PINS - Call your local BRP dealership |
| VCM |
710001884 |
PLUG - Call your local BRP dealership |
| VCM |
710001938 |
Plug |
| VCM |
710002032 |
MOLEX CONNECTOR COVER - Call your local BRP dealership |
| VIM1 |
409013700 |
Plug |
| VIM1 |
409210100 |
Clip Bracket Connector (edge) |
| VIM1 |
515176164 |
Male Terminal |
| VIM1 |
515176621 |
Wire Seal |
| VIM1 |
710000576 |
HOUSING, 4CIRCUITS - Call your local BRP dealership |
| VIM2 |
409209700 |
Female Housing, 4 Circuits |
| VIM2 |
515176621 |
Wire Seal |
| VIM2 |
710001340 |
Female Terminal |
| VSS1 |
710001117 |
FEMALE TERMINAL - Call your local BRP dealership |
| VSS1 |
710001118 |
Wire Seal |
| VSS1 |
710003729 |
Housing This part replaces 710001116. |
| VSS2 |
710001117 |
FEMALE TERMINAL - Call your local BRP dealership |
| VSS2 |
710001118 |
Wire Seal |
| VSS2 |
710003729 |
Housing This part replaces 710001116. |
| VSS4 |
710001117 |
FEMALE TERMINAL - Call your local BRP dealership |
| VSS4 |
710001118 |
Wire Seal |
| VSS4 |
710003729 |
Housing This part replaces 710001116. |
| YRS |
710001118 |
Wire Seal |
| YRS |
710003730 |
Housing This part replaces 710001120. |
| 186 |
219704424 |
Vinyl Tubing, Low Temp 3000Mm Long |
| 188 |
409902000 |
Tubing 12 mm |
| 253 |
219704425 |
Tubing 6 Mm 3000Mm Long |
| 331 |
219704446 |
PROTECTOR TUBE, 4MM 1000MM LONG - Call your local BRP dealership |
| 420 |
414115200 |
Tie-Rap 180 mm |
| 426 |
219704427 |
LOW TEMPERATURE TUBING 1/2? 3000MM LONG - Call your local BRP dealership |
| 765 |
Not |
Available As Spare Part - Adhesive Tape |
| 1150 |
710002025 |
WIRE HOLDER - Call your local BRP dealership |
| 1166 |
710002189 |
WIRE HOLDER COVER - Call your local BRP dealership |
