| Ref | Part Number | Description |
|---|
| 2 |
0331634 |
BAGUE, câble d'accélérateur |
| 3 |
0318286 |
CLAMP |
| 5 |
0328731 |
VIS, câble de verrouillage This part replaces 0329265. |
| 6 |
0304027 |
VIS, arbre de commande de sens de marche |
| 8 |
0316354 |
ENGINE COVER SUPPORT GROMMET |
| 9 |
0323474 |
HOOK, Cover to housing |
| 10 |
0321885 |
NIPPLE |
| 10 |
515178227 |
Multifunction Gauge Full Size Color |
| 11 |
0316002 |
SUPPORT, Front port |
| 13 |
0327196 |
SUPPORT, Front stbd |
| 14 |
0302406 |
SLEEVE |
| 15 |
0551793 |
SCREW |
| 16 |
0332170 |
LOWER COVER |
| 17 |
0303398 |
VIS, support |
| 18 |
0332169 |
SEAL, Steering arm |
| 20 |
0323474 |
HOOK, Cover to housing |
| 21 |
0300646 |
VIS, ancrage |
| 23 |
0330151 |
CLAMP, Harness to oil tank boss This part replaces 0309041. |
| 24 |
0551793 |
SCREW |
| 25 |
0307769 |
PLUG |
| 60 |
515178965 |
Gauge Support |
| 70 |
250000725 |
Screw M4 X 16 |
| 600 |
515179240 |
Terminal Dess One Wire |
| 610 |
278004274 |
Specialized Nut |
| 620 |
515179476 |
Grey, LYNX DESS Key |
| 800 |
515178645 |
Heated Visor Wiring Harness |
| 810 |
572103300 |
Cap |
| 1000 |
219400510 |
USB Outlet |
| 1010 |
515178190 |
Harness |
| 1040 |
515178153 |
Extension Harness |
| 2400 |
515178196 |
LH Switch Housing |
| 2410 |
515177147 |
Housing Plate |
| 2420 |
250000671 |
Torx Screw |
| 2470 |
415130141 |
Sleeve |
| 3211 |
515178202 |
Connector Coil |
