| Ref | Part Number | Description |
|---|
| 2 |
0174679 |
KIT JAUGE CORRECTION D'ASSIETTE/RELEVAGE |
| 5 |
0583255 |
LEAD ASSEMBLY |
| 9 |
0582093 |
LEAD ASSY This part replaces 0582092. |
| 10 |
515178227 |
Multifunction Gauge Full Size Color |
| 12 |
0583207 |
CABLE ASSY., Switch & gauge |
| 18 |
0512904 |
BULLET TERMINAL |
| 22 |
0512743 |
DISPOSITIF DE RETENUE |
| 23 |
0317000 |
COLLIER, câble |
| 24 |
0329182 |
VIS, borne |
| 25 |
0512776 |
BASE Junction box |
| 26 |
0583105 |
CABLE ASSY., Sending unit |
| 30 |
0583707 |
COVER ASSY |
| 31 |
0582671 |
LEAD ASSY. Junction box ground |
| 34 |
0583158 |
CONNECTOR |
| 39 |
0582986 |
CONN ASSY., Blue leads (trim up) |
| 39 |
0582987 |
CONN ASSY., Green leads (trim down) |
| 45 |
0315004 |
FIL DE LIAISON, bornier |
| 46 |
0315057 |
MOUNT, Bracket |
| 47 |
0512510 |
SLEEVE, Ground lead |
| 50 |
0329182 |
VIS, borne |
| 51 |
0331984 |
CLAMP, Hose |
| 52 |
0583909 |
CABLE, Junction box switch |
| 60 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 60 |
515178965 |
Gauge Support |
| 61 |
0512741 |
DISPOSITIF DE RETENUE, conn. de l'interrupteur thermostatique |
| 62 |
0303398 |
VIS, support |
| 63 |
0512790 |
SLEEVE, Motor & sending leads |
| 70 |
250000725 |
Screw M4 X 16 |
| 600 |
515179240 |
Terminal Dess One Wire |
| 610 |
278004274 |
Specialized Nut |
| 620 |
515179476 |
Grey, LYNX DESS Key |
| 800 |
515178645 |
Heated Visor Wiring Harness |
| 810 |
572103300 |
Cap |
| 1000 |
219400510 |
USB Outlet |
| 1010 |
515178190 |
Harness |
| 1040 |
515178153 |
Extension Harness |
| 2200 |
707000995 |
Pressure And Temperature Sensor |
| 2210 |
250000725 |
Screw M4 X 16 |
| 2400 |
515178196 |
LH Switch Housing |
| 2410 |
515177147 |
Housing Plate |
| 2420 |
250000671 |
Torx Screw |
| 2470 |
415130141 |
Sleeve |
| 2480 |
415130141 |
Sleeve |
| 2600 |
515177931 |
Emergency Stop Switch |
| 2610 |
515177310 |
Emergency Stop Switch Support |
| 2620 |
250000263 |
Torx Screw #8-18 |
| 5000a |
515177272 |
Capacitor |
| 5003 |
250200140 |
Washer |
| 5004 |
250200024 |
Rubber Washer 5 mm |
| 5005 |
250000724 |
Torx Screw M5 X 20 |
| 5010 |
515178430 |
Rubber Stopper |
| 5020 |
515178159 |
Module Support |
| 5025 |
207551634 |
Hex. Flange Screw, Scotch Grip |
| 0583107 |
0583107 |
JUNCTION BOX & COVER ASSY |
