| Ref | Part Number | Description |
|---|
| 1 |
3857853 |
CABLE ASSY., Engine |
| 2 |
0512902 |
RING TERMINAL This part replaces 3852245. |
| 6 |
0328074 |
CACHE, cosse prise This part replaces 3852181. |
| 8 |
3852527 |
RING TERMINAL |
| 11 |
3853565 |
CONNECTOR |
| 12 |
3852527 |
RING TERMINAL |
| 13 |
3854244 |
LEAD |
| 14 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet This part replaces 3852158. |
| 16 |
0914745 |
COVER This part replaces 3853320. |
| 19 |
3854192 |
CONNECTOR, Relay |
| 21 |
0512902 |
RING TERMINAL This part replaces 3852245. |
| 22 |
3854084 |
CABLE, Distributor |
| 25 |
3857181 |
NUT, Bracket |
| 26 |
0512742 |
DISPOSITIF DE RETENUE, connecteur This part replaces 3852237. |
| 28 |
0987704 |
CIRCUIT BREAKER, 50 Amp This part replaces 3854283. |
| 30 |
3853786 |
CLAMP INSTRUMENT CABLE |
| 31 |
3853620 |
SCREW, Circuit breaker |
| 32 |
3850234 |
ISOLATOR, Relay mounting |
| 34 |
3854138 |
RELAY, Engine control |
| 35 |
3852825 |
RETAINER, Engine cable |
| 36 |
3855938 |
SCREW, Cover |
| 37 |
3856764 |
COVER, Bracket |
| 38 |
3856186 |
BRACKET, Engine cable |
| 39 |
0941263 |
GROMMET, Bracket |
| 40 |
3857175 |
BRACKET, Electrical |
